5-40 Chapter 5: BIOS setup
5.5 Server Mgmt menu
The Server Mgmt menu displays the server mgmt status, and allows you to change
the settings.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Server Mgmt Event Logs Boot Monitor Security Tool Exit
BMC Firmware: 1.03
BMC Detect Timout 120
FRB-2 Timer timeout [6 minutes]
FRB-2 Timer Policy [Reset]
O/S Watchdog Timer [Disabled]
O/S Wtd Timer Timeout [10 minutes]
O/S Wtd Timer Policy [Reset]
System Event Log
BMC network conguration
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BMC Detect Timout [120]
Allows you to set the number of seconds to wait for BMC. Use the <+> and <->
keys to adjust the value.
FRB-2 Timer timeout [6 minutes]
Enter value between 3 to 6 minutes for FRB Timer Expiratin value.
Conguration options: [3 minutes] [4 minutes] [5 minutes] [6 minutes]
FRB-2 Timer Policy [Reset]
Allows to congure how the system should respond if the FRB2 Timer exprise. Not
available if FRB2 Timer is disabled.
Conguration options: [Do Nothing] [Reset] [Power Down]
O/S Watchdog Timer [Disabled]
If enabled, starts a BIOS timer which can only be shut off by Intel Management
Software after the OS loads. Helps determine that the OS sucessfully loaded or
follows the
O/S Boot Watchdog TImer Policy
.
Conguration options: [Enabled] [Disabled]
O/S Wtd Timer Timeout [10 minutes]
Allows to congure the length of the O/S Boot Watchdog Timer. Not available if
O/S
Boot Watchdog Timer
is disabvled.
Conguration options: [5 minutes] [10 minutes] [15 minutes] [20 minutes]
