5-38 Chapter 5: BIOS setup
5.4.14 ME Subsystem
Intel ME Subsystem Conguration
ME Subsystem [Enabled]
ME BIOS Interface Version 1.2
ME Version 2.1.5.43
ME FW Status Value : 0xf0345
ME FW State : SPS ME FW Active
ME FW Operation State: M0 without UMA
ME FW Error Code: No Error
ME Ext FW Status value: 0x3900e301
BIOS Booting Mode: Performance Optimized
Cores Disabled: 0
ME FW SKU Information: SiEn NM
ME Subsystem [Enabled]
Conguration options: [Disabled] [Enabled]
5.4.15 LegacyDevicesConguration
Serial Port 1 Conguration
Serial Port 2 Conguration
SerialPort1/2Conguration
Serial Port Conguration
Serial Port [Enabled]
Device Settings I0=3F8h; IRQ=4
Device Mode [Standard Serial Po...]
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
ME Subsystem Help.
Set Parameters of serial
Port 1(COM1).
Enable or Disable Serial
Port(COM).
