User's Manual

1.5.3 Motherboard-LayoutMotherboard-Layout
1.5.4 Layout-InhaltLayout-Inhalt
Anschlüsse/Jumper/Steckplätze/LED Seite Anschlüsse/Jumper/Steckplätze/LED Seite
1. Tastaturstrom (3-pol. KBPWR) 1-20 8. Standby-Strom LED (SB_PWR) 1-5
2. USB-Geräteaufweckkontakt (3-pol. USBPW1-6,
3-pin USBPW7-12)
1-20 9. Systemtafelanschluss (10-1 pol. F_PANEL) 1-25
3. AT�-Netzanschlüsse (24-pol. EAT�PWR, 4-pol.
AT�12V)
1-23 10. Lautsprecheranschluss (4-pol. SPEAKER) 1-23
4. CPU- und Gehäuselüfteranschlüsse (4-pol.
CPU_FAN und 3-pol. CHA_FAN)
1-22 11. USB 2.0-Anschlüsse (10-1 pol. USB78,
USB910, USB1112)
1-27
5. AMD FM1-Sockel 1-8 12. Digitaler Audioanschluss (4-1 pol. SPDIF_OUT) 1-26
6. DDR3 DIMM-Steckplätze 1-11 13. RTC RAM löschen (3-pol. CLRTC) 1-19
7. SATA 3.0Gb/s-Anschlüsse (7-pol. SATA3G_1~6) 1-24 14. Fronttafelaudioanschluss (10-1 pol. AAFP) 1-26
F1A55-M LX PLUS R2.0
PCIEX16_1
PCIEX16_2
PCIEX1_1
PCI1
F_PANEL
SPEAKER
CLRTC
KBPWR
USBPW1-6
USBPW7-12
AAFP
ATX12V
EATXPWR
CPU_FAN
CHA_FAN
Lithium Cell
CMOS Power
Super
I/O
ALC
887
RTL
8111E
DIGI
+VRM
64Mb
BIOS
SB_PWR
SPDIF_OUT
24.4cm(9.6in)
AMD
®
A55
DDR3 DIMM_A1 (64bit, 240-pin module) DDR3 DIMM_B1 (64bit, 240-pin module)
SATA3G_2
SATA3G_1
SATA3G_4
SATA3G_5 SATA3G_6
SATA3G_3
AUDIO
KB_USB56
LAN1_USB12
USB34
21.3cm(8.4in)
USB1112 USB910 USB78
VGA
LPT
COM1
SOCKET FM1
52 31 644
8
3
910111214 2
7
7
13
ASUS F1A55-M L� R2.0-Serie 1-7
