Chapter 2: Hardware information
Chapter 2
P8H77-V Motherboard Qualied Vendors Lists (QVL)
DDR3 1066 MHz capability
Side(s): SS - Single-sided DS - Double-sided
DIMM support:
• 1 DIMM:
Supports one (1) module inserted into any slot as Single-channel memory
conguration.
We suggest that you install the module into A2 slot.
•
2 DIMMs:
Supports two (2) modules inserted into either the blue slots or the black
slots as one pair of Dual-channel memory conguration.
We suggest that
you install the modules into slots A2 and B2 for better compatibility.
• 4 DIMMs:
Supports four (4) modules inserted into both the blue and black slots as
two pairs of Dual-channel memory conguration.
Visit the ASUS website for the latest QVL.
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
Crucial CT12864BA1067.8FF 1GB SS Micron 9GF22D9KPT 7 - • • •
Crucial CT25664BA1067.16FF 2GB DS Micron 9HF22D9KPT 7 - • • •
ELPIDA EBJ10UE8EDF0-AE-F 1GB SS ELPIDA J1108EDSE-DJ-F - 1.35V(low voltage) • • •
ELPIDA
EBJ21UE8EDF0-AE-F
2GB DS
ELPIDA J1108EDSE-DJ-F
-
1.35V(low voltage) •
•
•
Kingston KVR1066D3N7/1G(low
prole)
1GB SS ELPIDA J1108BFSE-DJ-F 7 1.5V • • •
Kingston KVR1066D3N7/2G 2GB DS ELPIDA J1108BDSE-DJ-F 7 1.5V • • •
Kingston KVR1066D3N7/4G 4GB DS Hynix H5TQ2G83AFR 7 1.5V • • •
Micron MT8JTF12864AZ-1G1F1 1GB SS Micron 9GF22D9KPT 7 - • • •
Micron MT16JTF25664AZ-1G1F1 2GB DS Micron 9HF22D9KPT 7 - • • •
Kingtiger
2GB DIMM PC3-8500
2GB DS
Hynix H5TQ1G83AFP G7C
-
- •
•
•
