Audio
VIA
®
VT1708S 8-channel high denition audio CODEC
- Supports jack-detection, multi-streaming and front panel
jack-retasking
- Optical S/PDIF out port at back I/O
USB
Intel
®
H77 Express Chipset - supports ASUS USB 3.0 Boost Turbo
Mode and UASP Mode*
- 2 x USB 3.0/2.0 ports at mid-board for front panel support
- 2 x USB 3.0/2.0 ports at back panel (blue)
Intel
®
H77 Express Chipset
- 10 x USB 2.0/1.1 ports (6 ports at mid-board, 4 ports at back
panel)
* The USB 3.0 ports only support Windows
®
7 or later versions.
UASP standard only supports Windows
®
8.
ASUS unique features
ASUS DIGI+ VRM
- ASUS DIGI+ VRM: Digital Power Design for the CPU and iGPU
- ASUS 6+1+2 Phase Power Design
ASUS Protect 3.0
- EPU
- ASUS Anti-Surge Protection
- Low EMI
- ESD
- 100% All high quality conductive polymer capacitors
ASUS Exclusive Features:
- ASUS AI Suite II
- TurboV
- GPU Boost
- MemOK!
- ASUS UEFI BIOS EZ Mode featuring graphics user interface
- USB 3.0 Boost featuring the latest USB 3.0 UASP standard
ASUS Quiet Thermal Solution:
- ASUS Fanless Design: Stylish heatsink solution and MOS heatsink
- ASUS Fan Xpert
ASUS EZ DIY:
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2 ASUS EZ Flash 2
- ASUS MyLogo 2™
ASUS Q-Design:
- ASUS Q-Slot
ASUS exclusive
overclocking features
Precision Tweaker 2:
- vCore: Adjustable CPU voltage at 0.005V increment
- vCCSA: 191-step system agent voltage control
- vDRAM Bus: 191-step Memory voltage control
- vPCH: 191-step Chipset voltage control
- iGPU: 127-step iGPU voltage control
- vCPU_PLL: 1-step CPU & PCH PLL voltage control
SFS (Stepless Frequency Selection):
- BCLK/PCIE frequency tuning from 80MHz up to 300MHz at 1MHz
increment
Overclocking Protection:
- ASUS C.P.R.(CPU Parameter Recall)
(continued on the next page)
P8H77-V specications summary
