Rear Panel I/O Ports 4 x USB 3.0/2.0 ports (blue)
4 x USB 2.0/1.0 ports (1 supports USB BIOS Flashback)
1 x PS/2 Keyboard/mouse port
1 x HDMI port
1 x Display port
1 x Mini-Display port
2 x eSATA ports
2 x LAN (RJ-45) ports (2 x Intel
®
LAN)
1 x Optical S/PDIF Out port
8-channel Audio I/O ports
Internal I/O connectors 10 x SATA 6.0Gb/s connectors (6 x yellow; 4 x dark brown)
1 x mSATA connector
1 x 4-pin CPU Fan connector supports both 3-pin (DC mode) and
4-pin (PWM mode) CPU coolers control
1 x 4-pin CPU Optional Fan connector (CPU_OPT)
4 x 4-pin Chassis Fan connectors
1 x Front panel audio connector (AAFP)
1 x S/PDIF out header
1 x TPM connector
1 x chassis intrusion header
1 x COM port
1 x 24-pin EATX Power connector
2 x 8-pin EATX 12V Power connector
1 x 6-pin EATX 12V_1 Power connector
1 x System Panel (Q-connector)
1 x MemOK! button
1 x Clear CMOS jumper
1 x mSATA switch jumper
1 x DirectKey button
1 x DRCT (DirectKey) connector
1 x EPU switch
1 x TPU switch (advanced 2-stage adjustments)
1 x Power on switch
1 x CHAFAN_SEL jumper
1 x Dr. Power switch
BIOS features 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM
BIOS 2.7, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, ASUS
CrashFree BIOS 3, My Favorites, Quick Note, Last Modied log,
F12 PrintScreen, F3 Shortcut functions, and ASUS DRAM SPD
(Serial Presence Detect) memory information
(continued on the next page)
Z87-WS specications summary
