SP1000M INSTRUCTION BOOK User Guide
CONTENTS Getting Started _01 Package Contents Product Overview Power Management Charging Connections Firmware Updates 02 03 05 06 07 12 Using the Device _02 Basic Operations Home Screen Notification Bar Music Services Using Open APP Service AK CONNECT Listening to Music Playlist Management USB DAC Installation How to Use USB Audio CD Ripping Settings Connecting to Wi-Fi Using Bluetooth Equalizer Setup 13 17 19 22 23 24 30 33 36 37 38 40 45 46 48 Miscellaneous _03 Safety Pre-Cautions Troubleshooting Cop
User Guide Package Contents Contents may be changed without prior notice to improve the performance or quality of the product. SP1000M microSD Card Slot Cover Leather Case & Protective Film USB Type-C Cable Quick Start Guide & Warranty Card Leather Case & Protective Film: Protect the device and its screen. microSD Card Slot Cover: The cover is used to protect the microSD card slot when not in use. It is installed in the product by default. USB Type-C Cable: For charging and data transfer.
User Guide Product Overview The appearance of the product, as well as the printed and engraved information, may vary depending on the model. 3.5mm Unbalanced Port Power 2.5mm Balanced Port microSD Card Slot USB Type-C Port Previous/Rewind Play/Pause Next/ Fast-Forward Volume LCD Touchscreen Home Button 3.5mm Unbalanced Port: - 3.5mm Unbalanced Port symbol. For audio output, connect earphones or headphones that utilize a 3.5mm jack. 2.5mm Balanced Port: - 2.5mm Balanced Port symbol.
User Guide Volume: Turn the wheel to adjust the playback output volume level. LCD Touchscreen: Display screen with touch control features. Previous/Rewind: Short press - Play the previous song or restart the current song. Press and hold - Rewind the current song. Play/Pause: Play or pause the current song. Next/Fast-Forward: Short press - Play the next song. Press and hold - Fast-forward the current song. Home Button: Press to return to the Home Screen.
User Guide Power Management Powering the Device On/Off 1. Press and hold the [Power ] button to turn on the device. 2. While the device is on, press and hold the [Power ] button to shut down the device. A confirmation message will appear. 3. Press [OK] to turn off the device. This device has an automatic shutdown feature to save battery power.
User Guide Charging Charging via USB Wall Adapter 1. Commercially available 9V 1.67A output adapters may be used for charging. Fast charging time: Approx. 2 hours 50 minutes (Fully discharged, Power-off, 9V 1.67A adapter) / Normal charging: About 5 hours 30 minutes (Fully discharged, Power-off, 5V 2A adapter) A fast charger of 9V 1.67A may be used. Using a 12V adapter will not charge the device and may cause malfunctions.
User Guide Connections 3.5mm Unbalanced Port 1. Connect earphones or headphones to the 3.5mm unbalanced port. OR 2.5mm Balanced Port 1. Connect earphones or headphones to the 2.5mm balanced port. OR Connecting to Balanced Audio Device 1. Connect to an external audio device by using the 3.5mm unbalanced port and 2.5mm balanced port.
User Guide Connecting to Computer 1. Turn on the device and your computer. 2. Use the USB Type-C cable to connect the device to a computer in accordance with settings in [Menu - Settings - USB Mode]. [Default] Media Device (USB Drive): Transfer files from a computer to the device. DAC Input: Listen to music on a connected computer through the device. (See Page 37) Mac users need to download and install Android File Transfer from the Astell&Kern website. [http://www.astellnkern.
User Guide Copy Files (Folders) to the Device 1. To copy files/folders from your computer, select the desired files/folders and drag & drop them into the device folder. Ensure the USB Type-C cable is properly connected. Turning off the device, computer or disconnecting the USB Type-C cable while copying or moving files/folders may corrupt files or device memory. File transfer speeds may be affected by the computer and/or the OS environment.
User Guide Delete Files (or Folders) from the Device 1. Select the file/folder to delete, right-click the mouse, and then select [Delete]. 2. Select [Yes] in the [Confirm File/Folder Deletion] window to delete the selected files/folders. Disconnecting from the Computer 1. Disconnect the USB Type-C cable after the transfer between the device and computer is complete. Disconnecting the device from the computer during a file transfer may corrupt data on the device.
User Guide Insert/Remove a microSD Card 1. Refer to the diagram and gently insert a microSD card into the microSD card slot. 2. To safely remove a microSD card, on the Home Screen, select [Safely remove SD card] from the Notification Bar or select [Unmount SD card] from [Menu - Settings - System Information]. 3. Gently press the microSD card in to unlock and release it from the slot.
User Guide Notes on Using a microSD Card If the microSD card is not recognized or functions improperly, format the card, preferably in the FAT32 system. Using cards other than the recommended microSD card types may cause malfunctions. A microSD card is not included in the product package. Please purchase separately. Firmware Updates Wi-Fi Update / OTA (Over-the-Air) 1. Connect to a wireless network. 2. If a new firmware update is available, the screen will display a Firmware Update Guide window. 3.
User Guide Basic Operations LCD Touchscreen 1. This device features an LCD touchscreen that allows you to perform operations by touch. Use the touchscreen to access various features on the device. To prevent damage to the screen, do not use a sharp object or excessive force. Return to the Home Screen 1. Press [ ] at any time to return to the Home Screen.
User Guide From the Home Screen, swipe your finger to the left, right, up or down from any edge of the touchscreen to access display menus. Each side of the Home Screen will activate a different display menu. Main Menu 1. From the left edge of the touchscreen, swipe your finger right to display the Main Menu. Music files extracted using the AK CD-Ripper accessory that are stored in the Ripping folder of the internal memory will be displayed in the CD library menu.
User Guide Notification Bar 1. From the top edge of the touchscreen, swipe your finger down to display the Notification Bar. View Current Playlist 1. From the right edge of the touchscreen, swipe your finger left to display the Now Playing menu.
User Guide View Play History 1. From the bottom edge of the touchscreen, swipe your finger up to display the Play History menu. Moving Up/Down on a List 1. Scroll through a list by dragging your finger up or down.
User Guide Home Screen 9 1 10 11 12 2 13 3 14 4 15 5 16 6 17 7 18 8 19 1 Menu Displays the Main Menu. 2 Details Displays current song information. 3 Song Progress Indicates song duration. 4 Recent Menu Go to the last displayed menu list. List 5 Add to Playlist Add the current song to a playlist. 6 Title Song title information. File name is displayed when the title is unavailable. 7 Artist/Album Displays the artist and album info.
User Guide 8 Previous/ Rewind Short press: Play the previous song or restart the current song. Press and hold: Rewind the current song. 9 Playlist Display current playlist. 10 Format Information Displays the bit rate and sampling frequency data. 11 Album Cover Displays album cover of current song. Tap image to view the song lyrics. 12 Now Playing Song Count Displays the current song number playing/ total number of songs in Now Playing.
User Guide Notification Bar 1 2 3 4 5 6 7 8 9 10 11 12 13 Using the Device 19
User Guide 1 Wi-Fi Press [ 2 Bluetooth Press [ ] to turn Bluetooth on/ 3 EQ ] to turn Wi-Fi on/off. off. Press [ ] to turn the EQ on/ off. The most recent EQ settings are applied by default. 4 Computer Select the mode to use when Connection connected to a computer. Mode : Listen to music on a connected computer through the device. [Default] : Enables transfer of media files. 5 USB Audio After connecting the device to a portable USB DAC, press [ ] to connect or disconnect the device.
User Guide 10 Settings Press [ ] to display the full settings menu. 11 Brightness 12 Notifications Device notifications are Display displayed in this area. Clear Notifications Clear notifications. Use the adjustment bar to control the display brightness. 13 Long-press an icon [ / / / / corresponding full settings menu screen.
User Guide Music Services Listen to streaming services or purchase music from Services in the Main Menu when connected to a wireless network. (Streaming services and ability to purchase music vary by country. Not all services are available in all countries.) Streaming or Purchasing Music 1. Connect to a wireless network. 2. Select [Services] from the Main Menu. 3. Select from the the list of service options available. 4. Check the user guide or help menu within each service for detailed information.
User Guide Using Open APP Service The Open APP Service enables the user to install specific APK music streaming apps to the device. Copy the desired APK into the Open Service folder of the product and install the relevant App in the Menu-Service of the product. The source of the app you are trying to install is unknown. Be aware that if the app is installed, the device may be damaged and personal data compromised. Depending on the APP, some functions may not work.
User Guide AK CONNECT Access and play back music files stored on a computer, NAS drive or AK Device on the same network, as well as output sound through compatible speakers with AK Connect. AK Connect is available on your AK device and also available as an app for your smartphone or tablet via Apple’s App store or Google Play Store. MQS Streaming Server for your Computer 1.
User Guide 5. A list of libraries / speakers that are on the same network with the AK player will be displayed. 6. Select a library / speaker to connect. 7. After selecting a library / speaker, select a category from the menu to display the corresponding music list. For Wi-Fi connections, see Page 45.
User Guide Streaming Music from Your Library 1. Select a category from the library menu to see your list of music. 2. Select a song to begin streaming. Downloading Music from Your Library 1. Select a category from the library menu to see your list of music. 2. Press [ ] button at the upper- right corner of the music list. 3. Select the desired music and press [ ] to initiate the download. A message on the Notification Bar will indicate when the download is complete.
User Guide AK Connect Usage Examples Case 1 SP1000M AK T1 LIBRARY SPEAKER Case 2 AK500N SP1000M AK T1 LIBRARY REMOTE SPEAKER Using the Device 27
User Guide Case 3 SP1000M AK500N REMOTE & LIBRARY SPEAKER Case 4 SP1000M AK500N AK T1 LIBRARY REMOTE SPEAKER Using the Device 28
User Guide Case 5 SP1000M LIBRARY or AK Connect APP REMOTE AK T1 SPEAKER AK500N LIBRARY Using the Device 29
User Guide Listening to Music Selecting Music 1. Select a category from the Main Menu to display the corresponding music list. 2. Select a song from the list to begin playback. Select [Folder] to search music by folder. Continuous Playing Time: Approx. 10 hours 30 minutes (Music: FLAC,16bit, 44.1kHz, Unbalanced, Volume 80, EQ Off, LCD Off) Supported Formats: PCM [8~384kHz(8/16/24/32bit)] DSD [2.8/5.6/11.2MHz] Listening to Music To search, press [ ] on the menu list and enter the title.
User Guide Press [ ] on top of the music list to view the options: : Select / deselect entire list : Add the selected list at the top / bottom / after the current song of Now Playing : Add selected list to a playlist : Delete selected list : Exit Turn the [Volume] wheel to adjust the volume. Press [ ] during playback to pause and [ ] to resume playback. Press [ / ] during playback for the previous/next track. Press and hold [ / ] to rewind/fast-forward the track.
User Guide Playlist Screen 1 3 4 2 1 Previous Return to the previous screen. 2 Playlist Display the current playlist. 3 Edit mode Display the editing options for the music list. 4 Play All Play all songs in the current list.
User Guide Playlist Management Creating a Playlist 1. Press [Playlists] on the menu to view the playlists. 2. Select [ + ] in the upper right corner of the screen. 3. Enter a name for the playlist, and then press [Add] to create a new playlist. Adding a Song to a Playlist 1. Press [Playlists] to display the list of playlists. 2. Select a playlist and press [+ Add Song] to display a list of songs by album. 3. Select a song and press [Add] to add the song to the selected playlist.
User Guide Removing a Song from a Playlist 1. Press [Playlists] to display the list of playlists. 2. Select the playlist to edit. 3. Press [ ] at the top, then select the song you want to delete from the playlist. 4. Press [ ] on top of the screen. 5. Press [DELETE] to remove the song from the selected playlist. This action will only remove the song from the selected playlist, not the memory. Playing a Playlist 1. Select the desired playlist for playback. 2.
User Guide Renaming a Playlist 1. Press [Playlists] to view the playlists, and press [ ]. 2. Select a playlist to be renamed. 3. Press [ ] at the top of the screen to display the RENAME window. 4. Enter a name for the playlist and then press [RENAME] to confirm the change. Deleting a Playlist 1. Press [Playlists] to view the playlists and press [ ]. 2. Select the playlist to be deleted. 3. Press [ ] at the top of the screen. 4. Press [DELETE] to delete the selected playlist.
User Guide USB DAC Installation The USB DAC function allows the device to be recognized as a sound card on a computer. Music from the computer is played through the device’s headphone port for an enhanced listening experience. USB DAC Specifications Supported OS Windows 7(32bit/64bit) / Windows 8(32bit/64bit) / Windows 10(32/64bit) MAC OS 10.7(Lion) or later USB DAC Support Specifications Supported Formats: PCM [8~384kHz(8/16/24/32bit)] DSD [2.8/5.6/11.
User Guide How to Use USB Audio Connect the device to a portable amp or DAC using USB Audio Out. How to Connect a Portable USB DAC 1. Connect the portable USB DAC to the AK device’s USB Type-C port with a dedicated cable. 2. Press [ 3. Once [ ] in the Notification Bar. ] is activated, you can enjoy music stored on the device through the connected portable USB DAC. The USB Type-C cable that comes packaged with the device is only to be used for computer data transfer or to charge the device.
User Guide CD Ripping CDs can be ripped directly to the device using the AK CDRIPPER (sold separately). Connecting the AK CD-RIPPER 1. Connect the AK CD-RIPPER to USB Type-C port of the device using the proper cable. 2. In the Notification Bar press [ ] to link the devices and activate the CD Ripping Menu. 3. When ripping is complete, before disconnecting, press [ ] on the Notification Bar to unlink/disconnect the devices.
User Guide 2. Connect AK CD-RIPPER and insert CD to display the [CD Ripping] notification at the bottom of the Notification Bar. 3. Press [CD Ripping] and select from the file format options of FLAC or WAV. 4. If Wi-Fi is turned on the Gracenote database will be searched for matching CD metadata after the file format is selected. 5. When the database search is complete, press [Start] to begin CD ripping.
User Guide Settings The settings menu allows users to customize the device. The settings menu may vary depending on the firmware version. Setup 1. Select [Main Menu - Settings] or select [ ] from the Notification Bar menu. 2. Select the feature to view setting options. Wi-Fi Change wireless network settings and turn Wi-Fi on/off See page 45 for more information on connecting to Wi-Fi. Bluetooth Connect a Bluetooth device to listen to music wirelessly.
User Guide Equalizer Set the equalizer according to the user's preferences. USER EQ: Adjust the frequencies according to the user's preferences. Supported Formats for EQ: PCM [8 ~ 192kHz(8/16/24bit)] Using the equalizer may negatively affect device performance. See pages 48 - 50 for more information on using the equalizer. Gapless Playback Plays the next song without any interruption. Gapless playback is only supported between two files with identical bit rates, sample rates, and channels.
User Guide CD Ripping Set the automatic CD ripping function as well as the file format and ripping speed. USB mode Media Device (USB Drive): When connected to a computer, device appears as a removable drive. DAC Input: Output sound from a connected computer to the device. USB Audio Select the type of DSD sound being outputted through USB Audio Out to a connected portable DAC. Screen Brightness Adjust screen brightness settings. Date & Time Set the current date and time.
User Guide Language Select the display language. Supported languages are English, Korean, Japanese, Chinese (Simplified/Traditional), French, Russian, German, and Spanish. Input Method Back Button: the Floating Back Button will be displayed on the screen. Move the Back Button to the desired position by dragging and dropping the icon with your finger. Move the button to the center of the screen to deactivate it.
User Guide When using AK Connect to download music, if the [Default folder] is selected in Settings, downloading will automatically begin to the pre-set Downloads folder. When [Select Folder] is selected, the user is prompted to choose a download folder each time a file is downloaded. Update System Update: Update the device when a new firmware version is available. Application Update: Update the default applications (including the Services) when new versions are available.
User Guide Connecting to Wi-Fi Connecting to a Wi-Fi Network 1. Press and hold [ ] from the Notification Bar or select [Menu - Settings - Wi-Fi] to display a list of available Wi-Fi networks. 2. Select the desired AP to connect to the wireless network. Additional information such as Wi-Fi password may be required depending on Wi-Fi settings. Networks requiring browser or other additional certifications are not supported.
User Guide Using Bluetooth Connect a Bluetooth device to listen to music wirelessly. Turning Bluetooth On/Off A Bluetooth device must be paired with the device prior to use. Refer to the Bluetooth device's instruction manual for details. 1. Select [ ] from the Notification Bar menu or select [On/Off] from [Menu - Settings - Bluetooth]. Bluetooth Pairing 1. In the Settings Menu, select the appropriate Bluetooth device from the list of available devices. Disconnect a Bluetooth Device 1.
User Guide Removing a Bluetooth Pairing 1. Press [ ] to the right of the paired device to go to settings. 2. Select [Remove] to complete the process. Bluetooth Support Specifications Profile: A2DP, AVRCP, aptX™HD Device performance may be affected during Hi-Res playback. Do not turn off the device while connected to Bluetooth. Turn the Bluetooth device off then on in case of issue. Pairing methods may differ for each individual Bluetooth device.
User Guide Equalizer Setup Equalizer Setup 1. Press and hold [ ] on the Notification Bar or turn on [Menu - Settings - Equalizer]. 2. Press [PRO EQ] to activate the drop-down menu and select [ + ]. 3. Enter a name for the custom EQ settings and select [SAVE].
User Guide 4. Adjust the frequencies up and down according to the user's preferences. 5. The number values at the lowerleft corner of the screen can be adjusted for fine-tuning. 6. Press the [Advanced] tab on the top to display PEQ settings screen. Adjust Freq/Gain/Q.
User Guide Deleting a Custom Equalizer Setting 1. Press on the drop-down menu at the upper-left corner of the screen to display the list of the saved EQ settings. 2. Press [ ] next to the EQ name to be deleted. 3. Press [OK] to delete the selected EQ setting. Renaming a Custom Equalizer Setting 1. Press on the drop-down menu at the upper-left corner of the screen to display the list of saved EQ settings. 2.
User Guide Safety PreCautions Device When a plug is inserted into the earphones, 2.5mm balanced, or USB port, do not apply any force or impact to the plug. Do not insert any metal objects (coins, hairpins, etc.) or flammable debris into the device. Do not put heavy objects on the device. If the device gets wet (rain, water, chemicals, medicine, cosmetics, sweat, moisture, etc.), allow the device to dry thoroughly before powering on. Contact the nearest IRIVER Customer Support Center for service.
User Guide Connecting the cable to a defective or damaged USB port on a computer may damage the device. Displaying one image for an extended period may cause screen burn-in (afterimage). Using poor quality protective films or adhesive stickers on the screen may cause damage. Do not insert any foreign objects into the device ports. The device may become warm while playing and charging, so handle it carefully. Product’s corners may be sharp, so handle carefully.
User Guide Troubleshooting Solutions to Common Issues 1. The device won't turn on. The battery may need to be recharged. Charge the device for at least one hour and try again. Reset the device. (See Page 5) 2. The device will not charge when connected to a computer via USB cable. Connect to the computer using the provided USB Type-C cable. Charging may not be performed depending on the condition of your PC. (In this case, charging with a PC is not recommended.
User Guide 7. A file does not play, or the product becomes unstable when a certain file is played. File may be damaged or corrupt if the following occurs: Playback stops or freezes. Device may act erratically or freeze. File may sound different on another device. There may be a difference in the performance of playback or other functions. There may be differences in the file specs. Converting the file to a different format or use of a different file is recommended.
User Guide Certifications KC / FCC / CE / TELEC Class B Device (Communication equipment for residential use): This is a Class B Device and is registered for EMC requirements for residential use. This device can be used in residential areas and all other areas.
User Guide Body-Worn Operation This device was tested for typical body-worn operations with the back of the portable music player kept 5mm from the body. To maintain compliance requirements, use only belt-clips, holsters or similar accessories that maintain a 5mm separation distance between the user’s body and the back of the portable music player, including the antenna. The use of belt-clips, holsters and similar accessories should not contain metallic components in its assembly.
User Guide Disclaimers The manufacturer, importer, and distributor shall not be liable for damages including accidental and personal injury due to the improper use or operation of this product. The information in this user manual was written based on current product specifications. The manufacturer, IRIVER Limited, regularly adds new features via OTA updates and will continue to apply new technologies in the future. Product specifications may be changed without prior notice.
User Guide Specifications General Specifications Product Name SP1000M Model PPF32 Body Color Lapis Blue Body Material Aluminum Display 4.1inch 720x1280 touch display Supported Audio WAV, FLAC, WMA, MP3, OGG, APE, AAC, ALAC, AIFF, Formats DFF, DSF Sample rate PCM : 8kHz ~ 384kHz (8/16/24/32bits per Sample) DSD Native: DSD64(1bit 2.8MHz), Stereo / DSD128(1bit 5.6MHz), Stereo / DSD256(1bit 11.2MHz), Stereo Output Level Unbalanced 2.1Vrms / Balanced 4.
