PS 155

SIMPLEX WIRELESS INTERFACE

Level

High

Low

Test

tone

Level

Release

VOX

CALL

PTT

Rx/Tx

Power

PS 155

wireless

interface

SIDETONE

TX CONTROL

Send

AUDIO LEVEL

Receive

Level

Release

CONTENTS

1.0 GENERAL DESCRIPTION..........................................3

2.0 UNPACKING...............................................................4

3.0 INSTALLATION...........................................................4

4.0 FRONT PANEL CONTROLS ......................................5

5.0 REAR PANEL CONNECTORS ...................................6

6.0 THE INTERCONNECTING CABLE.............................7

7.0 SIDETONE ADJUSTMENT PROCEDURE .................8

8.0 VOX ADJUSTMENT PROCEDURE............................8

9.0 TX MODE SWITCH ....................................................8

10.0 INTERNAL CONTROLS..............................................9

11.0 CABLING ..................................................................10

12.0 PARTYLINE TECHNICAL CONCEPT.......................11

13.0 TECHNICAL SPECIFICATIONS ...............................11

14.0 WARRANTY .............................................................11

15.0 PROBLEM SOLVING................................................12

16.0 BLOCK DIAGRAM ....................................................13

17.0 POSSIBLE SYSTEM DIAGRAMS.............................14

User Manual PS 155/ Issue 1

2000 ASL Intercom, Utrecht, Holland.

Summary of content (15 pages)

PAGE 1
R PRO SERIES USER MANUAL FOR THE PS 155 SIMPLEX WIRELESS INTERFACE AUDIO LEVEL Low Receive TX CONTROL SIDETONE Send High Level Test tone Level Release VOX PTT CALL PS 155 wireless interface Power Rx/Tx CONTENTS 1.0 2.0 3.0 4.0 5.0 6.0 7.0 8.0 9.0 10.0 11.0 12.0 13.0 14.0 15.0 16.0 17.0 GENERAL DESCRIPTION.......................................... 3 UNPACKING............................................................... 4 INSTALLATION.........................................................
PAGE 2
User Manual PS 155 / Issue 1 8 2001 ASL Intercom, Utrecht, Holland.
PAGE 3
1.0 GENERAL DESCRIPTION Located on the front panel are the Volume controls (send and receive), sidetone adjustment trimmers, test tone switch, VOX adjustment trimmers and TX mode control switch. In receive mode (Rx) the audio from the wireless system is sent to the wired intercom system, its volume can be controlled with the ‘Receive’ volume knob. In transmit mode (Tx) the audio signal from the wired intercom system is sent to the wireless system, its volume can be controlled with the ‘Send’ volume knob.
PAGE 4
2.0 UNPACKING The shipping carton contains the parts listed below: * The PS 155 * User manual * Sub-D 9 connector ASL has taken great care to ensure this product reaches you in flawless condition. After unpacking the unit please inspect for any physical damage to the unit, and retain the shipping carton and relevant packing materials for use should the unit need returning. If any are missing, contact your dealer.
PAGE 5
4.0 FRONT PANEL CONTROLS AUDIO LEVEL Low Receive Send 1 2 3 High 4 PS 155 wireless interface TX CONTROL SIDETONE Level 5 1 Receive VOLUME control knob This knob adjusts the level of the audio that is received from the wireless unit. 2 Send VOLUME control knob This knob adjusts the level of the audio that is send to the wireless unit. 3 SIDETONE low trimmer This trimmer adjusts the low frequency rejection of the sidetone. Please refer to section 7.0 for the proper adjustment procedure.
PAGE 6
5.0 REAR PANEL CONNECTORS In Link To transceiver PS 155 wireless interface Serialnumber : Intercom line 12 12 LINE connectors These XLR-3 connectors are for connecting the PS 155 to the intercom system. Pin assignments: 1. 0 V / ground shield 2. +30 V power wire 3. audio wire The female connector is for input. The male connector is for extending the intercom line to other user stations. 13 TRANSCEIVER connector A Sub-D 9 pole connector for the connection of the wireless unit. Pin assignments: 1.
PAGE 7
6.0 THE INTERCONNECTING CABLE Special care must be taken in constructing the interconnection cable. Although ASL-intercom has taken great care in shielding and filtering all RF components from the unit, it is still very important that you use the best quality cables and properly construct any electrical and mechanical construction. The TRANSMIT SWITCH contacts These are located on pins 4, 5 and 6. Most wireless units will need a contact to be closed to change from receive to transmit.
PAGE 8
7.0 SIDETONE ADJUSTMENT PROCEDURE 8.0 VOX ADJUSTMENT PROCEDURE • Connect the interface with a proper cable to the wireless unit. Before this procedure is done the SIDETONE must have been adjusted properly ! • If the wireless unit has a volume control turn it down (volume approx. 10%, a volume that is too high can cause problems such as distortion).
PAGE 9
10.0 INTERNAL CONTROLS To access these trimmers you need to open up the unit. Disconnect the unit of all other equipment and then remove the cover. - Open the PS 155 by removing the two screws at either side. Then carefully connect the unit to the intercom and to the wireless unit. OUTPUT GAIN (R4) The output gain can be adjusted internally by a trimmer R4. The trimmer is located on the PCB board at the left, near to the transformers. To increase mic gain turn clockwise.
PAGE 10
11.0 CABLING For the BASIC Series Intercom system the interconnecting cables are of the shielded twoconductor microphone cable type and the intercom line connectors are of the XLR-3 type. Audio and Call signals are on XLR pin 3, DC power is on XLR pin 2. XLR pin 1 is connected to the shield of the cable which functions as the common return for audio and power. ! Use high quality (multipair) cable.
PAGE 11
12.0 PARTY LINE, TECHNICAL CONCEPT ASL's Pro Series offers a complete two way ('full duplex') communications system. Users of the system are connected via a 'party line'. Master stations (with built-in power supply), beltpacks and power supplies are interconnected via standard microphone cable. One wire is used as an audio line, one as a power line and the screen of the cable functions as earth/return. Current drive is used for signal transfer.
PAGE 12
15.0 PROBLEM SOLVING PROBLEM CAUSE CHECK Unit does not respond No power supply or defective cable of the wired intercom. Power led and cable with another intercom station.
PAGE 13
16.0 BLOCK DIAGRAM User Manual PS 155 / Issue 1 8 2001 ASL Intercom, Utrecht, Holland.
PAGE 14
17.0 POSSIBLE SYSTEM DIAGRAMS A B A B User Manual PS 155 / Issue 1 8 2001 ASL Intercom, Utrecht, Holland.
PAGE 15
User Manual PS 155 / Issue 1 8 2001 ASL Intercom, Utrecht, Holland. 15 XLR-3 WALLBOX EARTHING CONCEPT OVERALL SHIELD + Z1 Z2 10R Z1/Z2 : LINE IMPEDANCES (BS210) OF MULTIPAIR CABLE AND/OR METAL CABLE TRUNK SEPARATE SHIELD 30V POWER SUPPLY ONE EARTHING POINT ONLY MAINS EARTH AMPCO SOUND LAB. B.V.
