USER GUIDE CAMPUS 300 Not the actual front page 801.250B USG/300/AE-B 12.05.95 Downloaded From projector-manual.
USER GUIDE CAMPUS 300 Downloaded From projector-manual.
USER GUIDE LCD PANEL 2 Downloaded From projector-manual.
USER GUIDE LCD PANEL TABLE OF CONTENTS INTRODUCTION ..................................................................................... 5 MAIN FEATURES.................................................................................... 5 SUPPLIED MATERIAL............................................................................. 6 SETTING UP THE LCD PANEL ............................................................... 7 COMPUTER..........................................................................
USER GUIDE LCD PANEL 1 This publication is printed on recycled paper. The information contained in this user guide is preliminary, and the products described herein are subject to change without prior notice. The symbols and are used in this publication to indicate Warning and Note respectively. 4 Downloaded From projector-manual.
USER GUIDE 2 LCD PANEL INTRODUCTION This LCD Data panel is a state of the art projection device that can be connected to most computers. Applications include presentations, software training, educational use, advertising, information boards and other situations where a small or large audience shares information. 3 MAIN FEATURES - 2.
USER GUIDE 4 LCD PANEL SUPPLIED MATERIAL A complete set includes the following components : 1. LCD Data Panel 2. VGA Cable 3. Cable-Adapt. MAC mon 4. Cable-Adapt. MAC comp. 5. Power -5, 12, 5 V 6. Power Cable 7. Remote Control 8. Batteries 9. Box 10. User Guide 6 Downloaded From projector-manual.
USER GUIDE 5 LCD PANEL SETTING UP THE LCD PANEL Switch off all equipment before connecting the components. Be aware of static electricity that may build up, especially in the dry season and when operating on synthetic carpets. Discharge any static electricity by touching a metallic surface before you start. Place the LCD panel on top of a transmissive overhead projector (OHP). Select a high intensity type projector, for instance 400 W halogen or metalhalide.
USER GUIDE 5.1 LCD PANEL COMPUTER Connect the LCD panel, computer, monitor and power supply as shown in the rear foldout. Connect cable (1) between the LCD panel and the computer. Use the Ysplit on the computer end to connect the monitor. If you have a Macintosh computer, insert applicable adapters (2) and (3) as shown. Connect the power supply to the LCD panel (4). TO SET UP FROM THE REMOTE CONTROL: STEP OPERATION 1 Press RESET for default settings 2 Adjust TUNE for a stable image.
USER GUIDE 6 LCD PANEL USING THE LCD PANEL The LCD panel has a set of connectors that you need to know in order to operate the device correctly. 6.1 REMOTE CONTROL The infrared remote control (RC) is the main user interface to the device. The RC is used to set the LCD panel correctly (to get the best possible viewing conditions) and to control the presentation. The figure shows the different keys of the remote control. * Grey area does not apply for this product.
USER GUIDE LCD PANEL The 'MEM' column in the tables below indicates whether the setting is memorized for each source. For a detailed overview, see the Features section.
USER GUIDE 6.2 LCD PANEL CONNECTORS All connectors are positioned on the right hand side of the LCD panel. See the technical data section for pinouts of the various connectors. Do not connect any other devices with similar plugs to the connectors of the LCD panel, as this voids any warranty and may cause permanent damage to the device. CONNECTOR POWER COMPUTER 6.
USER GUIDE 7 LCD PANEL FEATURES The LCD panel has a variety of different features implemented. This chapter explains each feature in detail. DUAL SAFECOOL SYSTEM The cooling operation is controlled by the overhead projector light (OHP). This safety feature ensures that the fans are always operating as long as the OHP is turned on. When the OHP is turned off, the fans automatically stop to minimize noise. The power supply must be attached to the panel for the fan to work properly.
USER GUIDE LCD PANEL CONTRAST The contrast of an image is defined as the relation between dark and light colors. An image of high contrast is often regarded as 'hard', as compared to the 'soft' feeling of a low contrast image. Low contrast is recommended for long term viewing, while high contrast is used to enhance details. Use the CONTR keys on the remote control (RC) to adjust the contrast. Also see Brightness. The contrast setting is stored individually for each mode.
USER GUIDE LCD PANEL POSITION Due to minor variations in graphic cards, the horizontal and vertical position may need adjustment. Select POSITION, then press LEFT and use the cursor keys. VGA text mode (720 x 400) is correctly displayed when the image is positioned appropriately. RESET This feature enables standard settings of most controls (see the 'MEM' column in the remote control description, where YES also indicates a standard setting). RESET will only reset the mode active.
USER GUIDE 8 LCD PANEL PRACTICAL HINTS AND TIPS This is a list of what to do when things go wrong. Check the symptoms carefully if you experience any problem. The cure may be at your hands! Always press the RESET key first. This ensures that the panel is in a defined state.
USER GUIDE LCD PANEL The remote control is not working - Check if the batteries need replacement - Be sure to point at the projection screen or directly at the IR eye in the front of the LCD panel - You may be too far away from the panel (max. distance 7m/ 23 feet) 16 Downloaded From projector-manual.
USER GUIDE 9 LCD PANEL MAINTENANCE From time to time, the housing and protection glasses may be cleaned with a damped, non abrasive cloth, possibly using a mild detergent to remove spots. The upper protection glass is not removable, as it only needs cleaning from the outside (the inside is sealed to the LCD module). The lower protection glass can be removed for cleaning. The glass may be hard to get out, as the springs holding the glass are designed to avoid the glass falling out .
USER GUIDE LCD PANEL 11 TECHNICAL DATA The technical data may change without prior notice in order to improve the product performance. The apparatus is designed for indoor use and should not be operated outside the general environmental limits, as this may lead to permanent damage and violation of any warranties.
USER GUIDE LCD PANEL DISPLAY UNIT Full color (RGB) unit connecting directly to external video sources. SIZE WEIGHT POWER LCD CELL COLOR RESOLUTION RESPONSE TIME CONTRAST RATIO PIXEL RESOLUTION SCREEN DIAGONAL VIDEO FREQUENCY HORIZONTAL SYNC VERTICAL SYNC COMPUTER INPUT DEFECTIVE PIXELS APPROVALS 310 x 310 x 40 mm 12.2 x 12.2 x 1.6 inch 1600 grams / 3.6 lbs -5, -12, 5 V Active matrix TFT stripe configuration 2.1 million (colors 30 ms 100:1 640 x 480 x 3 (RGB) 8.
USER GUIDE LCD PANEL POWER SUPPLY Primary switched universal type AC to DC converter. INPUT VOLTAGE OUTPUT VOLTAGES CONNECTOR APPROVALS 100 to 250 VAC +5VDC, +12VDC, -5VDC 5 pin DIN male TÜV, UL, CSA, N, S, D, FI REMOTE CONTROL Infrared wireless remote control. BATTERIES RANGE 2 pcs LR03/AAA 1.5V penlight 7 m/23 feet COMPATIBILITY The unit is predefined for the following interfaces.
USER GUIDE LCD PANEL 12 CONNECTORS The pinouts of all external connectors are described. POWER This connector feeds regulated DC power to the panel. 2 4 5 1 3 1 2 3 4 5 5 PIN DIN FEMALE (FRONT VIEW) GND GND +5VDC -5VDC +12VDC COMPUTER This connector relays all sync and data signals from the computer to the panel and back again to the CRT monitor.
USER GUIDE LCD PANEL 13 FCC STATEMENT This equipment has been certified to comply with the limits for a Class A computing device, pursuant to Subpart J of Part 15 of FCC rules. Only peripherals (computer input/output devices, terminals, printers, etc.) certified to comply with the Class A limits may be attached to a computer that complies with Class A limits. When connecting to a peripheral device, a shielded input/output cable is required to ensure compliance with FCC rules.
USER GUIDE LCD PANEL 14 ENVIRONMENTAL STATEMENT This product is manufactured to minimize the stress and pollution of the surroundings. Where possible, recyclable materials are used. ITEM PACKAGING MECHANICS ELECTRONICS LCD MODULE RECYCLING / HANDLING Only recyclable materials are used Only recyclable plastics and metal is used. Recycling codes are moulded in the plastic. Metal parts are painted aluminium and steel. No CFC is used during manufacture. No components that require special handling are used.
USER GUIDE 15 LCD PANEL SERVICE INFORMATION In cases where a problem cannot be solved by the assistance of your dealer, please call the following number to get an RMA (Return Authorization Number) : +47 69 34 01 55 (Norway) To return the defective unit, package well (preferably using the original packaging material), enclose a copy of your sales receipt and a description of the problem you experience, and ship prepaid to : ASK AS Customer Service Department RMA ................
USER GUIDE LCD PANEL 16 CONNECTION LAYOUT The foldout shows how to connect the LCD panel to the computer. 25 Downloaded From projector-manual.
