1.9 Product Electrical Specification
Power Supply (Recommend) Regulated linear power supply, +12VDC, 300mA
Operating Voltage Range +9VDC - + 24VDC
Operating Current at +12VDC
Maximum Cable Distance
85mA (average) –250mA (peak)
150meters (500feet)
(base on Belden 9538 24AWG 0.6mm, 8 core
cable
foilshield) (for wiegand interface)
(base on Belden 9534 24 AWG 0.6mm, 4 core
cable
foilshield) ( for RS485 interface )
Read Range
<=50mm (2”)
( Read Range is dependent on local installation
conditions )
Transmit Frequency 13.56MHz
LED
Tri Color – Red, Green, Amber
Buzzer
Multi-tone
Operating temperature Range
-20°C to 50°C
Colour
Black
Material
High Heat ABS
Weight
250 grams
Dimension
135mm (Height) X 76mm (Width) X 21mm (Thickness)
Wire Termination
9 conducting wire at length approx. 300mm
Reader Mode
Card Only, Card and PIN.
PIN Input
1 – 6 Digits
Keypad
3 x 4 Keys
Communication Interface
RS485 or Wiegand ( Selectable )
Wiegand interface Output bit
format
26, 32, 37, 40, 56, 80, 168(Asis) bits format and
8-digit 32, 37, 40 bits format
Support Card Type
Mifare ( ISO 14443-A, ISO 14443-B)
EZ-Link
Output CAN or CSN (Selectable)
Mounting
Reader back casing mount
