Configuring WAN Connections
Configuring Frame Relay connections
Pipeline User’s Guide Preliminary January 30, 1998 1-27
Configuring a Frame Relay profile
To define the Frame Relay profile:
1
Open Ethernet > Frame Relay > profile.
For example:
Name=PacBell7
Active=Yes
Call Type=Nailed
FR Type=DTE
LinkUp=No
Nailed Grp=1
Data Svc=64k
Dial #=N/A
Link Mgmt=T1.617D
N391=6
DTE N392=3
DTE N393=4
DCE N392=
DCE N393=
T391=10
Station=CPEB
Active=Yes
Encaps=FR
Encaps options...
FR Prof=PacBell
DLCI=58
See profile above.
Station=CPEC
Active=Yes
Encaps=FR
Encaps options...
FR Prof=PacBell
DLCI=59
See profile above.
Table 1-1. Frame Relay and gateway profiles (continued)
Connection profiles (gateway) Frame Relay profile
