Configuring the Pipeline as a Bridge
Configuring bridged connections
Pipeline User’s Guide Preliminary January 30, 1998 5-13
An example IPX client bridge (local clients)
In the following example, the local Ethernet supports NetWare clients, and the
remote network supports NetWare servers and clients.
Figure 5-3. An example IPX client bridging connection
To configure the Pipeline in this example:
1
Open the System profile.
2
If the Pipeline does not already have a system name, assign one.
For example:
Name=SITEAGW
3
Close the System profile.
4
Open the Ethernet profile.
5
Open the Ether Options submenu.
6
Set the IPX Frame type.
IPX Frame=802.3
7
Close the Ethernet profile.
8
Open a Connection profile.
9
Set these parameters:
Station=SITEBGW
Active=Yes
Encaps=PPP
Route IPX=No
Bridge=Yes
Dial Brdcast=Yes
WAN
