Configuring IPX Routing
Configuring IPX routing connections
Pipeline User’s Guide Preliminary January 30, 1998 4-25
Station=NetWareClient1
Active=Yes
Encaps=PPP
Route IPX=Yes
Encaps options...
Send Auth=CHAP
Recv PW=*SECURE*
Send PW=*SECURE*
IPX options...
Peer=Dialin
5
Close the Connection profile.
An example with NetWare servers on both sides of the link
In the following example the Pipeline is connected to an IPX network that
supports both servers and clients. The example shows how it will make the
connection to a remote site that also supports both servers and clients.
Figure 4-2. A connection with NetWare servers on both sides
In this example, site A and site B are both existing Novell LANs that implement
NetWare 3.12 and NetWare 4 servers, NetWare clients, and a Pipeline. The
NetWare server at site A is configured with the following information
:
Name=SERVER-1
internal net CFC12345
WAN
NET=9999ABFF
Ethernet
NET=1234ABCD
Site B
Site A
NetWare servers
and clients
NetWare servers
and clients
