Installation and Operation Manual

www.arvratech.com
1.T-35 Specification
Item Specification
CPU 32bit Microcontroller + 240Mhz H.264 Codec MPU
Memory 64MB RAM + 128MB Flash
Firmware Update By USB Flash Memory
LCD 3.5” TFT Color LCD
Touch Screen Capacitive glass full touch screen
Video Play H.264 (MPEG4)
RF 13.56 Mhz
Card formats ISO 14443A/B, 15693, EMVO
Wiegand D0, D1, Pass LED, Fail LED, Buzzer, Tamper
Sound Supported
Power 12V (9~ 40V Input)
Current 100mA
Size 120 X 70 X 17mm
Operation Temperature -20 ~ 70°C
