Specifications

Code Function Monitor/Setting Range Initial Setting
A Group: Standard Functions
Code Function Monitor/Setting Range Initial Setting
d01
Output frequency monitor 0.0 ~ 360.0 Hz -
d02 Output current monitor 0.00 ~ 999.9 A -
F (forward run)
d03 Running direction monitor
r (reverse run)
-
w
(stop)
d04 Process variable (PV), PID feedback value monitor 0 ~ 9999
-
d05 Intelligent input terminal status monitor -
d06 Intelligent output terminal status monitor -
d07 Scaled output freguency monitor -
d08 Trip event monitor --
d09 Trip history monitor --
F01 Output frequency setting 0.5 ~ 360 Hz -
F02 Acceleration time 1 setting 0.1 ~ 3000 s 10.0s
F202 2ndsetting acceleration time 1 setting 0.1 ~ 3000 s 10.0s
F03 Deceleration time 1 setting 0.1 ~ 3000 s 10.0 s
F203 2ndsetting deceleration time 1 setting 0.1 ~ 3000 s 10.0s
F04 Motor direction setting 00:Forward/01:Reverse 00:Forward
A
-- Extented function of A group setting A01 ~ A98 -
B -- Extented function of B group setting b01 ~ b92 -
C -- Extented function of C group setting C01 ~ C95 -
H -- Extented function of H group setting H01 ~ H234 -
Monitoring Functions and Main Profile Parameters
Monitor
Setting
Expanded
Function
.
Potentiometer (Front Case)
A01 Frequency Commanding
.
Control terminal
Control terminal
.
Digital panel
A02 Run Commanding
.
Control terminal
.
Digital panel
A03 Base frequency setting 50 ~ 360 Hz
xxE type:50Hz
xxU type:60Hz
A203 2nd setting base frequency setting 50 ~ 360 Hz
xxE type:50Hz
xxU type:60Hz
A04 Maximum frequency setting 50 ~ 360 Hz
xxE type:50Hz
xxU type:60Hz
A204 2nd setting maximun frequency setting 50 ~ 360 Hz
xxE type:50Hz
xxU type:60Hz
A11 External frequency setting start 0.0 ~ 360 Hz 0.0 Hz
A12 External frequency setting end 0.0 ~ 360 Hz 0.0 Hz
A13 External frequency start rate setting 0 ~ 100% 0%
A14 External frequency end rate setting 0 ~ 100% 100%
A15 External frequency start pattern setting
Set frequency of A11 / 0 Hz 0 Hz
A16 External frequency sampling count setting 1 ~ 8 times 8 times
A20 Multispeed frequency setting (Speed 0)
A220 2nd setting multispeed frequency setting (Speed 0)
0 ~ 360 Hz 0 Hz
A21
Multispeed frequency setting (Speed 1~ Speed 15)
A35
A38 Jogging frequency setting 0.00 ~ 9.99 Hz 1.0 Hz
.
Free-run stop
A39 Jogging stop operation selection
.
Controlled deceleration
Free-run stop
.
DC braking to stop
Basic
Setting
Analog
Input
Setting
Multispeed
Freq.
Setting
~
Function List
‘‘ xxE type’’ and ‘‘ xxU type’’ in the tables below refer to the model types for Europe and North America, respectively.
Display the status of the intelligent terminals
(Input, Output)
(Output frequency (Hz))
T
(frequency converted value b86 )
Control terminal
9
