Specifications

Address Range: 0xfe000000-0xfe200000
Monitor Usage: 0xfe1d0000-0xfe1f9310 Locked.
MFS Usage : 0xfe1c0000-0xfe1d0000
Serial Port Baud Rate: 38400
#
------ End of output --------
Update the configuration files
Check if the new configuration files
vxbsp.ini and mdr.ini (mdr_server.ini and/or
mdr_host.ini
according to your configuration) are different from than the configura-
tion files present on your MDR system. If so then transfer the new configuration files
(
vxbsp.ini and/or mdr.ini) one by one as shown in the following method below:
a) First, the files which need to be updated have to be deleted as follow:
# rm vxbsp.ini (only if vxbsp.ini needs to be updated)
# rm mdr.ini (only if mdr.ini needs to be updated)
b) The configuration files should be transferred one by one with the
mgf command.
Both the file name and the file size need to be specified as arguments (because
the XMODEM protocol does not support communication of these parameters) as
follows:
# mgf vxbsp.ini 225 (only if vxbsp.ini needs to be updated)
# mgf mdr.ini 766 (only if mdr.ini needs to be updated)
Note: The file sizes used above are given as examples and should not be used. The
real sizes of the configuration files present on the VMETRO Software Products CD-
ROM may differ. Please find out the size of these files before trying to download
them.
The mmon.ini file supplied by VMETRO is a generic file and must NOT be up-
loaded in any case. The items contained in this file MUST be updated using the
iset
command.
Erase the Flash Memory of the MIDAS board by using the command
ef as follows:
# ef fe000000 1c0000
Start the downloader in the MIDAS Monitor by using the
dos command as follows:
# dos fe000000
Send the
mdrvxst.hex file across the serial line from your terminal program using the
XMODEM protocol.
If your system has more than one MDR board, steps above should be repeated.
Modify the serial line speed of your terminal program 9600 bauds and reset the MDR
board. The MDR system will reboot, the MDR Server will start automatically and, after
an initialization phase, will wait for a client to connect.
MDR User Guide 91
