Specifications

98 MDR User Guide
DPIO-DI & DPIO-DO
Input and output models for differential signaling using RS422 signaling.
• 32-bit parallel I/O RS422 up to 10 MHz
Packing Options
The DPIO can be set up to use different packing options. This is done by reloading a
“Packing PLD” on the DPIO. VMETRO provides a PLD Reprogramming Kit (part no.
PLD-KIT-DPIO) for this purpose. The kit contains everything that is needed: a PC
parallel port cable, JEDEC files for all packing options, and software.
Input/Output port Packing PCI
32 bit (D31:D00) No packing 32 bit
16 bit (D15:D00) 2 to 1 packing 32 bit
10 bit (D09:D00) 3 to 1 packing 30 bit (databits 31
or 30 not in use)
8 bit (D07:D00) 4 to 1 packing 32 bit
4 bit (D03:D00) 8 to 1 packing 32 bit
