Installation Guide

24
Step 3: Front Wall
24BA
You will need for this page:
Wall Channel
Assembly
1
WALL CHANNEL ASSEMBLY
(Painted)
Floor Channel
Assembly
1
Corner Clip
2
10280
FLOOR CHANNEL ASSEMBLY
(UNPAINTED)
10280
10280
Channel
START ASSEMBLY AT CORNER PANEL
CORNER MUST BE AGAINST
45 DEGREE CUT ON CHANNEL
IMPORTANT
CORNER MUST BE AGAINST
45 DEGREE CUT ON CHANNEL
Channel
START ASSEMBLY AT CORNER PANEL
IMPORTANT
10268
(QTY: 4)
(QTY: 4)
A
A
A
