Operating and installation instructions
CODI
®
S/B - Condensate collection / steam distribution
4.3 Diagram
Refer to the data sheet for information about materials with designations and figure numbers.
Fig. 2: CODI
®
S - series 671/672 PN40-63
primary connection DN25-50 / secondary connection DN15-25
Fig. 3: CODI
®
B - series 675/676 PN40-63
primary connection DN25-50 / secondary connection DN15-25
Safety back seat
(when fully opened valve)
Variant
Open-close function
Variant
Throttling function
Condensate collection
Steam distribution
Condensate collection
Steam distribution
or
Variant
Open-close function
Variant
Throttling function
Condensate collection
Steam distribution
Condensate collection
Steam distribution
Retaining element acts as bellow
seal non-rotation lock
Safety back-sealing mechanism
when valve fully open
