Table Of Contents

Dimensions

Important - Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Assembly Instructions - Please keep for future reference

Issue 1 - 02/06/10

Chrome Tidy Rail

Width - 84.5cm

Depth - 42.5cm

Height - 99.5/167cm

875/7049

Summary of content (6 pages)

PAGE 1
Chrome Tidy Rail Assembly Instructions - Please keep for future reference 875/7049 Dimensions Width - 84.5cm Depth - 42.5cm Height - 99.
PAGE 2
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the components and tools listed on page 2. • Remove all fittings from the plastic bags and separate them into their groups. • Keep children and animals away from the work area, small parts are a chokong hazard. • Make sure you have enough space to layout the parts before starting. • Assemble on a pad to avoid damaging the unit or your floor.
PAGE 3
Components - Panels If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the panels listed below 1 Rail x 1 (84cm) 2 Bottom tube x 2 (78cm) 3 Lower side support x 2 (86cm) 4 Upper side support x 2 (78cm) Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
PAGE 4
Assembly Instructions Step 1 Note: It would be useful to ask someone to help you at this stage. a: Insert Bottom tubes C a: 2 C . into Leg section A 2 2 C b: Insert Lower side supports 3 C .
PAGE 5
Assembly Instructions Step 2 Note: It would be useful to ask someone to help you at this stage. a: Insert Rail 1 into a: 1 A A Connectors A . b: Insert Upper side b: A A support 4 into Connectors A . 4 4 c: Insert Castors D A c: C.
PAGE 6
Assembly Instructions Step 3 Note: It would be useful to ask someone to help you at this stage. a: 4 4 a: Insert Locks AB into the top of Lower side support 3 . Insert Upper side support 4 into the Locks A B . Don’t tighten the Locks B until the next step of A height setting. b: Set the height of the unit. B Ensuring the Locks A are loosened, slide the Upper side support 4 to the desired height B and tighten the Locks A to affix in position as shown in fig.1. B B 3 3 b: 4 B Adjustment Range: 99.
