Assembly Instructions

Locking pin x 5
Locking nut 13mm x 5
Dowel x 20
45mm Screw x 13
Phillips screwdriver
(medium & large)
Flatblade screwdriver
(medium)
Small
hammer
Ruler/tape
measure
Components - Fittings
Please check you have all the fittings listed below
Tools required
Ruler - Use this ruler to help correctly identify the screws
A
B C
D
E
3
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
105
110 115 120 125 130 135 140 145 150 155 160 165 170
Cap x 8
Wall strap x 1
F
15mm Screw x 1
G
H
Wall plug x 1
26mm Screw x 1
I
