Ashley Dolls House Bookcase Assembly Instructions - Please keep for future reference 719/1785 Dimensions Width - 69cm Depth - 30cm Height - 89.
Safety and Care Advice Important - Please read these instructions fully before starting assembly Check you have all the components and tools listed on pages 2 and 3. Remove all fittings from the plastic bags and separate them into their groups. Keep children and animals away from the work area, small parts could choke if swallowed. Make sure you have enough space to layout the parts before starting. Do not stand on the panels, this could cause damage.
Components - Panels If you have damaged or missing components, call the Customer Helpline:08456 400800 Please check you have all the panels listed below 1 Back A x 2 (59.6 x 24.6cm) 2 Back B (59.6 x 35.5cm) 6 Left side (68.3 x 26.8cm) 7 Right side (68.3 x 26.8cm) 8 Upper shelf (59 x 26.7cm) 3 Bottom (65 x 29cm) 4 Lower shelf (59 x 26.7cm) 9 Top (69x 30cm) 5 Middle (24 x 25.
Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Assembly Instructions Step 1 a: 5 Fitting the dowels 8 a: Insert Dowels into Middle 5 ,Upper shelf 8 Lower shelf 4 , Left side 66 and Right side 7 . C C 4 C 6 7 b: Screw in Locking pins cB into Upper shelf 8 . b: B B 8 A c: Use Locking nut A to fix Middle 5 onto Upper shelf 8 .
Assembly Instructions Step 2 Fitting shelves a: a: Use Screws D to fix Back A 1 and Lower shelf 4 onto the unit. D 4 1 b: b: Use Screws D to fix Left side 6 and Right side 7 onto the unit. Use Caps E to cover the holes on the unit. E D 6 7 c: Insert Back A 1 c: into the unit. Use Screws D to fix Bottom 3 onto the unit.
Assembly Instructions Step 3 Fitting the top B a: a: Screw in Locking pins B cB into Top 9 . 9 A b: Insert Back B 2 into the unit. Use Locking nuts A to fix Top 9 onto the unit.
Assembly Instructions Step 4 F a: Fixing to wall G Note: It would be useful to ask someone to help you at this stage. It is strongly recommended that the unit is attached to the wall using Wall straps CF . Important: When drilling into walls always check that there are no hidden wires or pipes etc. Make sure that the screws and wall plugs supplied are suitable for supporting the unit. Consult a qualified tradesperson if you are not sure.
A Guide to - Wall Mounting & Fixings Important note: If plastic wall plugs are supplied with your product: Important: When drilling into walls always check that there are no hidden wires or pipes etc. Make sure that the screws and wall plugs being used are suitable for supporting your unit. Consult a qualifed tradesperson if you are unsure. Hints: - these are only suitable for use in masonry walls. If you are in any doubt about the correct wall plugs for your wall, seek professional advice.
