Assembly Instructions

A
Tools required
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
110 115 120 125 130 135 140 145 150 155 160 165 170
105
Components - Fittings
Please check you have all the fittings listed below
64mm Bolt x 16 32mm Bolt x 16
B
28mm Bolt x 4
C
Note: The quantities below are the correct amount to complete the assembly of 4 chairs. In some cases
more fittings may be supplied than are required.
Nut x 4
D E
F
H I
J
Insert nut x 16
Plain washer x 16
Spring washer x 36
Bolt cap x 16
Flatblade screwdriver
3
Wrench x 1 Hex key x 1
K
(supplied in the fittings pack of table)
G
Curved washer x 20
