Assembly Instructions

Please check you have all the fittings listed below
Tools required
3
Components - Fittings
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
A
Wooden dowel (F22) x 8
B
Metal dowel (F901) x 14
D E
Large locking
nut (F900) x 8
G H I
K
Rule Scissors Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Small locking
nut (F3) x 6
C
Nail (F51) x 12
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
J
Drawer runner (F1004) x 6 Handle (F930) x 3
see malibu fitment mk2 for large number of panels and fittings
25mm Screw (F50) x 6 9mm Screw (F74) x 6 9mm Screw (F73) x 12
F
Knock-in Peg (F171) x 12
M
Plastic Nail (F91) x 4
L
Wedgefix (F639) x 6
