Assembly Instructions

3
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
110 115 120 125 130 135 140 145 150 155 160 165 170
105
D
Mattress stopper x 4
A
B
M6 x 45mm Bolt x 4 M6 x 12mm Bolt x 12
C
M6 x 25mm Bolt x 4
E
Bolt nut x 4
Allen key x 2
F
