Hearts Bed With 4 Poster Frame Assembly Instructions - Please keep for future reference 323/8130 333/9613 Dimensions Width - 197cm Depth - 94cm Height - 189cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 640 0800 Issue 1 - 08//10/14
Safety and Care Advice Important - Please read these instructions fully before starting assembly IMPORTANT! KEEP FOR FUTURE REFERENCE • Keep children and animals away from the work area, small parts could choke if swallowed. • Check you have all the components and tools listed on the following pages. • During assembly do not stand or put weight on the product, this could cause damage. • Remove all fittings from the plastic bags and separate them into their groups.
Components - Parts If you have damaged or missing components, call the Customer Helpline: Argos = 0345 640 0800 Please check you have all the parts listed below 1 Headboard (94 x 63 x 3.2cm) 2 Footboard (94 x 76 x 3.2cm) 3 Headboard leg x 2 (38 x Ø3.2cm) 4 Siderail x 2 5 Headboard Upper Post x 2 6 Footboard Upper Post x 2 7 Top Rail Long x 2 8 Top Rail Short x 2 9 Slat x 24 (191.5 x 11 x 2.5cm) (120 x 6.5 x Ø3.2cm) (87.5 x Ø1.6cm) (100 x 6.5 x Ø3.2cm) (191 x Ø1.6cm) (91 x 4 x 2.
Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Assembly Instructions Step 1 1 Assembling headboard legs Insert headboard legs 3 into holes on headboard 1 as shown. 3 3 1 3 Step 2 Assembling headboard Attach siderails 4 to headboard 1 & 3 as shown and fix through holes using bolts B and bolt nuts D . Important: Fasten bolts & nuts using 2 allen keys F but do not fully tighten at this stage.
Assembly Instructions Step 3 C Assembling footboard 2 4 Attach footboard 2 to siderails 4 as shown and fix through2 holes using bolts C . C Important: Fasten bolts using allen key F but do not fully tighten at this stage. C 4 4 C C 2 C Step 4 8 Assembling short top rails Attach upper posts 5 C C 5 5 8 & 6 into holes on short top rail 8 as shown and fix through holes using bolts C . Important: Fasten bolts nuts using allen key F but do not fully tighten at this stage.
Assembly Instructions a: Step 5 5 Attaching upper rails a: Insert headboard upper post 5 onto posts of headboard 1 as shown. 1 5 5 b: Fix through holes Important: Fasten bolts using allen key F but do not fully tighten at this stage. b: C using bolts C as shown. C 5 6 1 Repeat above steps to assemble the footboard upper post 6 . C C 6 1 C 1 6 Step 6 A Assembling top rails Attach top rails 7 to upper rails 5 & 6 as shown and fix through holes using bolts A .
Assembly Instructions Step 7 9 Attaching slats Insert each slats 9 into holes on side rails 4 . Lock it into position by pushing firmly down with your hand. 4 Note: Make sure the slat is aligned to the hole before pushing it firmly down. Important: After all slats are positioned, tighten all bolts & nuts fixed in previous steps using allen keys F . 9 x24 4 4 Step 8 Attaching mattress stoppers Insert the mattress stoppers E into holes on the side rails 4 as shown. Assembly is complete.
