Installation Guide

CONTACT YOUR LOCAL POST OFFICE BEFORE INSTALLING THE MAILBOX TO ENSURE ITS CORRECT PLACEMENT AND HEIGHT AT THE

STREET. GENERALLY, MAILBOXES ARE INSTALLED AT A HEIGHT OF 41-45 INCHES FROM THE ROAD SURFACE TO INSIDE FLOOR OF THE

MAILBOX OR POINT OF MAIL ENTRY (LOCKED DESIGNS) AND ARE SET BACK 6-8 INCHES FROM THE FRONT FACE OF CURB OR ROAD

EDGE TO THE MAILBOX DOOR.

Lay post pieces on a ﬂat surface, making sure

to align the screw holes.

Carefully slide the plastic bracket over the top

post and let it rest on the heads of the sheet

metal screws.

Tools (not included)

Join the two post pieces together using the 3

sheet metal screws.

DO NOT overtighten. Tighten only until snug.

Attach the mounting plate to the post using

the 4 small hex bolts, nuts and 8 small

washers.

Insert the bolt and one washer

through inside of the post and

secure with another washer and

nut from the outside.

3” Round Post with Cover & Mailbox

Model 950080

ASSEMBLY INSTRUCTIONS

Hardware (included)

x 3, large sheet metal screws

To join the two post pieces:

x 8, small washers

x 4, small nuts

x 4, small hex bolts

To attach the mounting plate

to the post:

x 8, large washers

x 4, large nuts

x 4, large hex bolts

To attach the mailbox to the plate:

x 4, small Phillips screws

To join the two decorative covers:

One Phillips Screwdriver

Two Wrenches

- or -

PAGE 1
3” Round Post with Cover & Mailbox Model 950080 R ASSEMBLY INSTRUCTIONS CONTACT YOUR LOCAL POST OFFICE BEFORE INSTALLING THE MAILBOX TO ENSURE ITS CORRECT PLACEMENT AND HEIGHT AT THE STREET. GENERALLY, MAILBOXES ARE INSTALLED AT A HEIGHT OF 41-45 INCHES FROM THE ROAD SURFACE TO INSIDE FLOOR OF THE MAILBOX OR POINT OF MAIL ENTRY (LOCKED DESIGNS) AND ARE SET BACK 6-8 INCHES FROM THE FRONT FACE OF CURB OR ROAD EDGE TO THE MAILBOX DOOR.
PAGE 2
4 Install the assembled post into the ground. Ensure that the mounting plate is facing toward the street before installing into the ground. 5 Attach the mailbox to the mounting plate using the 4 large hex bolts, 8 large washers, and 4 large nuts. x4 Pay particular attention to the location, height, and distance from the street. A concrete footing is highly recommended. Typical post depths range from 12”-18” and may vary based on your installation application.
