Installation & Assembly

900-3223
1. Screw 2 x wheels onto bottom of front wire
then 2 x wheels onto bottom of back wire.
2. Attach front 、back、left、right wire
together with M5X25 screws.
3. Assembly top wire (2 x top wire meshes)
on top of the body with M5X25 screws.
4. Slide grill in space underneath the
front door.
5. Put 4 x seed guards in place above bar
around the body.
6. Slide tray in space underneath front
seed guard .
7. Screw 3 x door feeders on inside of 3 x doors.
8. Open the front door and put perch from
left to right inside the body.
Box List
Item No: 900-3223
Box 1/2 Worker Q C ganger
Part name Quantity
Front wire(前网) 1pcs
Back wire(后网) 1pcs
Left wire(左网) 1pcs
Right wire(右网) 1pcs
Seed guards(裙边) 4pcs
Grill(密网) 1pcs
Assembly
Instructions(包装图)
1pcs
Perch(木棍) 1pcs
Box 2/2 Worker Q C ganger
Top wire(盖网) 2pcs
Tray(铁盆) 1pcs
Wheels(2寸8厘米脚轮) 4pcs
Feeders(5寸杯) 3pcs
Holder(5寸合圈) 3pcs
Screw bag(螺丝包) 1pcs
