1.7. Assumptions

This manual assumes you are using a DANFOSS PROFIBUS Option Card in conjunction with a

DANFOSS FC 100, 200 or 300 Series. It is also assumed that your master is a PLC or PC equipped

with a serial communication card supporting all the PROFIBUS communication services required

by your application, and that all requirements stipulated in the PROFIBUS standard, as well as

those set up in the PROFIBUS Variable Speed Drive Profile and its company-specific implementa-

tion PROFIdrive, as well as those pertaining to the VLT Variable Speed Drive are strictly observed

as well as all limitations therein fully respected.

1.8. Hardware

These Operating Instructions relate to the Profibus fieldbus option type no. 130B1100 and type

no. 130B1200.

The Profibus Option will be identified as: MCA 101 Profibus DP V1 in par. 15-60

Option in Slot A

1.9. Background Knowledge

The DANFOSS PROFIBUS Option Card is designed to communicate with any master complying

with the PROFIBUS standard. Familiarity with the PC or PLC you intend to use as a master in your

SYSTEM is assumed. Issues regarding hardware or software produced by other manufacturers are

beyond the scope of this manual, and are not the responsibility of DANFOSS.

If you have questions regarding set-up of master-to-master communication, or communication to

a non-Danfoss slave, please consult the appropriate manuals

1.10. Available Literature

The following literature is available for the FC 100, 200 and 300 series.

Title

Literature no.

VLT HVAC Drive FC 100 Operating Instructions MG.11.AX.YY

VLT HVAC Drive FC 100 Design Guide MG.11.BX.YY

VLT HVAC Drive FC 100 Programming Guide MG.11.CX.YY

VLT AQUA Drive FC 200 Operating Instructions MG.20.NX.YY

VLT AQUA Drive FC 200 Design Guide MG.20.MX.YY

VLT AQUA Drive FC 200 Programming Guide MG.20.OX.YY

VLT AutomationDrive FC 300 Operating Instructions MG.33.AX.YY

VLT AutomationDrive FC 300 Design Guide MG.33.BX.YY

VLT AutomationDrive FC 300 Programming Guide MG.33.MX.YY

VLT AutomationDrive FC 100, 200 and 300 PROFIBUS Operating

Instructions

MG.33.CX.YY

VLT AutomationDrive FC 100, 200 and 300 DeviceNet Operating In-

structions

MG.33.DX.YY

VLT AutomationDrive FC 300 MCT 10 Software Dialogue MG.33.EX.YY

PROFIBUS DP V1 Design Guide MG.90.EX.YY

X = Revision number

Y = Language code
