This network reads the status on the digital
inputs from the frequency converter. If digital
input 18 is On it will stop the frequency con-
verter.
This network will reverse the motor when dig-
ital input 19 is ON, because par. 8-54
Revers-
ing select
is programmed to Logic AND.
This network will activate the relay 02.
