6.3. PROFIBUS-specific Parameter List

Par.

No. #

Parameter description Default value Range Conver-

sion index

Data

type

8-01 Control Site Dig. & ctrl. word [0] [0 - 2] - Uint8

8-02 Control Word Source FC RS485 [0] [0 - 4] - Uint8

8-03 Control Word Timeout Time 1 0.1-18000 -1 Uint32

8-04 Control Word Timeout Function Off [0] [0 - 10] - Uint8

8-05 End of Timeout Function Hold set-up [0] [0 - 1] - Uint8

8-06 Reset Control Word Timeout Do not reset [0] [0 - 1] - Uint8

8-07 Diagnosis Trigger Disable [0] [0 - 3] - Uint8

8-10 Control Word Profile FC profile [0] [0 - x] - Uint8

8-50 Coasting Select *Logic OR [3] [0 - 3] - Uint8

8-51 Quick Stop Select *Logic OR [3] [0 - 3] - Uint8

8-52 DC Brake Select *Logic OR [3] [0 - 3] - Uint8

8-53 Start Select *Logic OR [3] [0 - 3] - Uint8

8-54 Reversing Select *Logic OR [3] [0 - 3] - Uint8

8-55 Set-up Select *Logic OR [3] [0 - 3] - Uint8

8-56 Preset Reference Select *Logic OR [3] [0 - 3] - Uint8

8-90 Bus Jog 1 Speed 100 rpm 0 - par. 4-13 67 Uint16

8-91 Bus Jog 2 Speed 200 rpm 0 - par. 4-13 67 Uint16

9-15 PCD Write Configuration - - - Uint16

9-16 PCD Read Configuration - - - Uint16

9-18 Node Address 126 1 - 126 0 Uint8

9-22 Telegram Selection - [0 - 108] - Uint8

9-23 Parameter for Signals - 0 - 573 - Uint16

9-27 Parameter Edit Enabled [1] [0 - 1] - Uint16

9-28 Process Control Enable cyclic master [1] [0 - 1] - Uint16

9-44 Fault Message Counter 0 [0 - 8] 0 Uint16

9-45 Fault Code 0 - - Uint16

9-47 Fault Number 0 - - Uint16

9-52 Fault Situation Counter 0 0 - 1000 0 Uint16

9-53 Profibus Warning word 0 16 bits 0 V2

9-63 Actual Baud Rate No baud rate found [255] 9.6-12000 kbits 0 Uint8

9-64 Device Identification 0 [0 - 10] 0 Uint16

9-65 Profile Number 0 8 bits 0 Uint8

9-70 Edit Set-up Active set-up [9] [0 - 9] - Uint8

9-71 Save Data Values Off [0] [0 - 2] - Uint8

9-72 Drive Reset No action [0] [0 - 2] - Uint8

9-80 Defined Parameters (1) - 0-115 0 Uint16

9-81 Defined Parameters (2) 0-115 0 Uint16

9-82 Defined Parameters (3) - 0-115 0 Uint16

9-83 Defined Parameters (4) - 0-115 0 Uint16

9-90 Changed Parameters (1) - 0-115 0 Uint16

9-91 Changed Parameters (2) - 0-115 0 Uint16

9-92 Changed Parameters (3) - 0-115 0 Uint16

9-93 Changed Parameters (4) - 0-115 0 Uint16

16-84 Comm. Option STW 0 0 - FFFF 0 V2

16-90 Alarm Word 0 0 - FFFF 0 Uint32

16-92 Warning Word 0 0 - FFFF 0 Uint32

Please refer to the relevant Operating Instructions for a comprehensive parameter list.

VLT

Profibus 6. Parameters
