Operating instructions

[1] Bus Activates Preset Reference selection via the serial communica-
tion port or fieldbus option.
[2] Logic AND Activates Preset Reference selection via the fieldbus/serial com-
munication port, AND additionally via one of the digital inputs.
[3]
*
Logic OR Activates the Preset Reference selection via the fieldbus/serial
communication port OR via one of the digital inputs.
NB!
This parameter is active only when par. 8-01
Control Site is set to [0] Digital and
control word
.
8-90 Bus Jog 1 Speed
Range: Function:
100
RPM
*
[0 - par. 4-13 RPM] Enter the jog speed. This is a fixed jog speed activated via the
serial port or fieldbus option.
8-91 Bus Jog 2 Speed
Range: Function:
200
RPM
*
[0 - par. 4-13 RPM] Enter the jog speed. This is a fixed jog speed activated via the
serial port or fieldbus option.
9-15 PCD Write Configuration
Array [10]
None
3-02 Minimum Refer-
ence
3-03 Maximum Refer-
ence
3-12 Catch Up/Slow
Down Value
3-41 Ramp 1 Ramp
Up Time
3-42 Ramp 1 Ramp
Down Time
3-51 Ramp 2 Ramp
Up Time
3-52 Ramp 2 Ramp
Down Time
3-80 Jog Ramp Time
3-81 Quick Stop
Ramp Time
4-11 Motor Speed
Low Limit [RPM]
4-13 Motor Speed
High Limit [RPM]
6. Parameters VLT
®
