5CONSHELF XIV USER'S MANUAL
2.1 PRODUCT DESCRIPTION
The Conshelf XIV consists of the basic Conshelf rst stage and Conshelf
second stage assembly. It is available in the standard version or the Supreme
cold water (38°F+) version and both versions are U.S. Navy ANU listed.
First Stage
• The Conshelf XIV rst stage is machined from Marine Brass and
chrome plated for durability.
• Capable of pressures up to 4350 psi with the DIN version.
• Adjustable Intermediate Pressure.
• Convertible to Supreme or Dry Environment versions.
• Available in Yoke
• DIN Conversion Kit available.
Second Stage
• The Conshelf XIV second stage is formed from Marine Brass and
chrome plated for durability.
• Multiple mouthpieces are available for a comfortable t.
• Installed external lever height adjustment port for easy 2nd stage
adjustment.
2. INTRODUCTION
Congratulations and thank you for choosing Aqua Lung. Your new
regulator meets all existing standards for quality and performance and
has been designed and manufactured with the greatest care.
Perhaps, more than any other item of equipment that you have bought,
the better care you take of your regulator, the better it will perform for
you. Its performance will be guaranteed through annual inspection/
servicing by an Authorized Aqua Lung Technician. Before diving with
your new Aqua Lung regulator it is important that you read this manual
in its entirety so that you can familiarize yourself with its features and
the rules for using the regulator before, during and after the dive so
as to retain optimum performance for the years to come.
Conshelf XIV Conshelf XIV Supreme
First Stage Technology Diaphragm Regulator Diaphragm Regulator
Maximum Working Pressure Yoke: 3300 PSI / 232 Bar
DIN: 4350 PSI / 300 Bar
Yoke: 3300 PSI / 232 Bar
DIN: 4350 PSI/ 300 Bar
Medium Pressure 140 ± 5 PSI 125 ± 5 PSI
Number / Size of Ports 1 HP 7/16", 4 MP 3/8" 1 HP 7/16", 4 MP 3/8"
Hose Length 30 " / 762 mm 30 " / 762 mm
Technical Specications
