Operating instructions

3
IMMEDIATELY INSPECT FOR SHIPPING DAMAGE
All containers should be examined for damage before and during unloading. The freight carrier has
assumed responsibility for its safe transit and delivery. If equipment is received damaged, either apparent
or concealed, a claim must be made with the delivering carrier.
A) Apparent damage or loss must be noted on the freight bill at the time of delivery. It must then
be signed by the carrier representative (Driver). If this is not done, the carrier may refuse the
claim. The carrier can supply the necessary forms.
B) Concealed damage or loss if not apparent until after equipment is uncrated, a request for
inspection must be made to the carrier within 15 days. The carrier should arrange an
inspection. Be certain to hold all contents and packaging material.
Installation and start-up should be performed by a qualified installer who thoroughly read, understands and
follows these instructions.
LOCATION OF DATA PLATE
The data plate is located on the back of the unit.
!
!
NOTICE: The unit when installed, must be electrically grounded and comply with local codes, or in
the absence of local codes, with the national electrical code ANSI/NFPA70- latest edition.
Canadian installation must comply with CSA-STANDARD C.22.2 Number 0 M1982 General
Requirements-Canadian Electrical Code Part II, 109-M1981- Commercial Cooking Appliances.
GENERAL INFORMATION & TROUBLESHOOTING
!
!
NOTICE: Local codes regarding installation vary greatly from one area to another. The National
Fire Protection Association, Inc. states in its NFPA96 latest edition that local codes are “Authority
Having Jurisdiction” when it comes to requirement for installation of equipment. Therefore,
installation should comply with all local codes.
General Installation Instructions:
1. Always clean equipment thoroughly before first use. (See general cleaning instructions.)
2. Check rating label for your model designation and electrical rating.
3. Position equipment on level counter and plug into a grounded outlet so the plug is accessible. (See
individual description for electrical loads.) On units bearing the CE marking, the appliance must be
connected by an earthing cable to all other units in the complete installation and, hence, to an
independent earth connection.
Safety Precautions 2
General Information & Troubleshooting 3
DS-1A Mr. Frank Display Steamer 4
DR-1A Mr. Frank Display Broiler w/BH-1A Bun Warmer 5
Wiring Diagrams: DR-1A, DR-2A and DS-1A 5
Parts Lists & Exploded Views 6
DR-1A, DR-2A, BH-1A 6
DS-1A 7
Warranty 8
CONTENTS
!
!
WARNING: Disconnect device from electrical power supply and place a Tag Out-Lockout on the
power plug, indicating that you are working on the circuit.
!
!
CAUTION: Maintenance & repair should be handled by a factory authorized agent. Before doing
any maintenance or repair, contact APW Wyott.
