Specifications

30
Controller (series ML and KTV)
Digital temperature control
A variety of
alarm indication/output functions
Temperature setting resolution:
Switchable between 1°C and 0.1°C
Range of temperature setting:
Constant type 5.0-45.0°C
Reference temperature follow-
up type
-9.9 to +9.9°C
The controller is provided with rich alarm
indication/output functions, including equipment
abnormality alarms (individual alarm indication and
batch output) and temperature upper/lower limit
alarm (setting, indication, and output)
Useful Start timer function
OIL MATIC is equipped with the Start timer, which is used for starting the equipment, that
allows you to set the time at 0.5-hour intervals up to 99.5 hours maximum.
Selectable control modes
Chiller ON-OFF control, Gas bypass ON-OFF control
Switchable between constant type (controls temperature to the preset temperature) and
reference temperature follow-up type (controls temperature following the reference
temperature)
* The lights are being turned on for photographic purpose only, and the lighting may be different
from the actual state.
Parameter indic
ating LED
RUN lamp
Turns on during
operation
(Turns off at alarm)
Data indicating LED
UP key
(key for
increasing set value)
DOWN key
(key for
decreasing set value)
ENT key
Key for indicating current temperature
PARA key
Key for setting parameters
TMR key
Key for setting Start timer
(for models with timer)
POW key
Key for starting/stopping
OIL MATIC
