Specifications
Specifications of OIL MATIC
S
pecification
Specifications (series MRCC and MLCC)
Series MRCC specifications
Inverter control method
Model
MRCC-07 MRCC-15
Effective cooling capacity
(W)
0-4000 0-6000
Nominal chiller capacity
(W)
450 700
Refrigerant used R-407C
Amount of refrigerant filled
(g)
1130 2150
Condenser Forced air-cooled type cross-fin
Rated output of fan motor
(W)
60
Cooler (evaporator) Shell and tube
Heating exchange method Constant-flow forced circulation
Size of connected pipes
(IN×OUT)
RC3/4×RC3/4
Power source AC200V 50/60Hz, AC220V 60Hz, 3-phase
Maximum operating current
(A)
8 12
Normal operating current
(A)
― 9
Temperature regulator Digital inverter controller
Setting range
Constant type (5-45°C),
follow-up type (reference temperature: -9.9°C - +9.9°C)
Range of ambient temperature 5-45 (°C)
Range of liquid temperature 5-45 (°C)
Fluid to use Coolant, etc.
Appearance Light gray
Dimensions
(W×D×H (mm))
440×625×1260 650×800×1420
Weight
(kg)
110 180
* The operating current indicates the normal operating current, not the maximum operating current.
* The effective cooling capacity indicates the maximum values within the range of use when oil ISO VG2 or equivalent is used.
* Specifications are subject to change without notice for improvement.
Series MLCC specifications
ON-OFF control method
Model
MLCC-05 MLCC-07 MLCC-15
Effective cooling capacity
(W)
(50/60Hz)
1450/1740 2900/3480 4830/5810
Nominal chiller capacity
(W)
500 750 1500
Refrigerant used R-407C
Amount of refrigerant filled
(g)
900 800 2200
Condenser Forced air-cooled type cross-fin
Rated output of fan motor
(W)
45 60
Cooler (evaporator) Shell and tube
Heating exchange method Constant-flow forced circulation
Size of connected pipes
(IN×OUT)
RC3/4×RC3/4
Power source AC200V 50/60Hz, AC220V 60Hz, 3-phase
Maximum operating current
(A)
5 10
Normal operating current
(A)
―
Temperature regulator Digital ON-OFF controller
Setting range
Constant type (5-45°C),
follow-up type (reference temperature: -9.9°C - +9.9°C)
Range of ambient temperature 5-45 (°C) 5-40 (°C) 5-45 (°C)
Range of liquid temperature 5-45 (°C)
Fluid to use Coolant, etc.
Appearance Light gray
Dimensions
(W×D×H (mm))
410×625×1205 440×625×1260 650×800×1420
Weight
(kg)
90 100 180
* The operating current indicates the normal operating current, not the maximum operating current.
* The effective cooling capacity indicates the maximum values within the range of use when oil ISO VG2 or equivalent is used.
* Specifications are subject to change without notice for improvement.
