Specifications

Specifications of OIL MATIC
S
pecification
Specifications (series ML)
Series ML (without tank) specifications ON-OFF control method
Model
MLSA-03
MLHA-03
MLLA-03
MLSA-05
MLHA-05
MLLA-05
MLSA-07
MLHA-07
MLLA-07
MLSA-11
MLHA-11
MLLA-11
MLSA-15
MLHA-15
MLLA-15
MLSA-22
MLHA-22
MLLA-22
MLSA-38
MLHA-38
MLLA-38
Effective cooling capacity (W)
(50/60Hz)
1160/1390 1450/1740 2900/3480 3720/4460 4830/5810 7260/8720 12200/14650
Nominal chiller capacity (W) 300 500 750 1100 1500 2200 3750
Refrigerant used R-407C
Amount of refrigerant filled (g)
580 850 1000 1400 1670 2700 4200
Condenser Forced air-cooled type cross-fin
Rated output of fan motor (W)
25 60 60×2 85×2
Cooler (evaporator) Cylindrical multitubular type
Heating exchange method
Constant-flow forced circulation
Solution-sending pump type Trochoid gear pump
Rated output of motor (W)
200 400 750 750 1500
Flow rate (L/M) (50/60Hz)
12/14.4 24/28.8 30/36 39/46.8 58.5/70.2
Total relief pressure (Mpa)
0.5
Size of connected pipes
(IN×OUT)
RC1/2×RC1/2
RC3/4
×RC1/2
RC3/4×RC3/4 RC11/4×RC1
Power source AC200V 50/60Hz, AC220V 60Hz, 3-phase
Maximum operating current (A)
3 5 7 10 15 22 35
Normal operating current (A)
― ― ― ― ― ― ―
Temperature regulator Digital setting, indicated temperature controller
Setting range
Constant type (5-45°C),
follow-up type (reference temperature: -9.9°C - +9.9°C)
Range of ambient temperature 5-45 (°C)
Range of liquid temperature 5-45 (°C)
Fluid to use Mineral operating oil, lubricant oil, heat medium oil, etc.
Appearance Light gray
Dimensions (W×D×H (mm)) 360×420×815 360×420×915 390×440×944 435×520×1215 505×550×1250 605×575×1480 735×725×1740
Weight (kg) 50 70 70 110 120 185 300
* The effective cooling capacity indicates values when oil ISO VG32 or equivalent is used at the oil temperature and an ambient
temperature of 35°C.
* Specifications are subject to change without notice for improvement.
Series ML (with tank) specifications ON-OFF control method
Model
MLSB-03 MLSB-05 MLSB-07 MLSB-11 MLSB-15 MLSB-22 MLSB-38
Effective cooling capacity (W)
(50/60Hz)
1160/1390 1450/1740 2900/3480 3720/4460 4830/5810 7260/8720 12200/14650
Nominal chiller capacity (W) 300 500 750 1100 1500 2200 3750
Refrigerant used R-407C
Amount of refrigerant filled (g)
580 850 1000 1400 1670 2700 4200
Condenser Forced air-cooled type cross-fin
Rated output of fan motor (W)
25 60 60×2 85×2
Cooler (evaporator) Cylindrical multitubular type
Heating exchange method
Constant-flow forced circulation
Solution-sending pump type Trochoid gear pump
Rated output of motor (W)
200 400 750 750 1500
Flow rate (L/M) (50/60Hz)
12/14.4 24/28.8 30/36 39/46.8 58.5/70.2
Total relief pressure (Mpa)
0.5
Size of connected pipes
(IN×OUT)
RC1/2×RC1/2
RC3/4
×RC1/2
RC3/4×RC3/4 RC11/4×RC1
Reservoir tank capacity (L) 15 24 37 65 123
Power source AC200V 50/60Hz, AC220V 60Hz, 3-phase
Maximum operating current (A)
3 5 7 10 15 22 35
Normal operating current (A)
― ― ― ― ― ― ―
Temperature regulator Digital setting, indicated temperature controller
Setting range
Constant type (5-45°C),
follow-up type (reference temperature: -9.9°C - +9.9°C)
Range of ambient temperature 5-45 (°C)
Range of liquid temperature 5-45 (°C)
Fluid to use Mineral operating oil, lubricant oil, heat medium oil, etc.
Appearance Light gray
Dimensions (W×D×H (mm)) 360×420×815 360×420×915 390×440×944 435×520×1215 505×550×1250 605×575×1480 735×725×1740
Weight (kg) 70 80 90 135 150 275 400
* The effective cooling capacity indicates values when oil ISO VG32 or equivalent is used at the oil temperature and an ambient
temperature of 35°C.
* Specifications are subject to change without notice for improvement.
