Specifications

Specifications of OIL MATIC
S
pecification
Specifications (series C and CL)
Series C specifications Inverter control method
Model
C 300 C 750 C 500 C 2200
Effective cooling capacity (W) 0-2000W 0-4000W 0-6000W 0-8000W
Nominal chiller capacity (W)
300W or
equivalent
750W or
equivalent
1500W or
equivalent
2200W or
equivalent
Refrigerant used R-407C
Amount of refrigerant filled (g) 360 520 740 1120
Condenser Forced air-cooled type parallel flow type
Rated output of fan motor (W) 25 60 150
Cooler (evaporator) Plate-type heat exchanger
Heating exchange method Constant-flow forced circulation
Solution-sending pump type Trochoid gear pump
Rated output of motor (W) 200 400 750
Flow rate (L/M) (50/60Hz) 12/14.4 24/28.8 30/36 39/46.8
Total relief pressure (Mpa) 0.5
Size of connected pipes (IN×OUT) RC1/2×RC1/2 RC3/4×RC1/2 RC3/4×RC3/4 RC11/4×RC1
Power source AC200V 50/60Hz, AC220V 60Hz, 3-phase
Maximum operating current (A) 9 11 14 22
Normal operating current (A) 7 8 11 19
Temperature regulator Digital inverter PID controller
Setting range
Constant type (5-45°C),
follow-up type (reference temperature: -9.9°C - +9.9°C)
Range of ambient temperature 5-45 (°C)
Range of liquid temperature 5-45 (°C)
Fluid to use Mineral operating oil, lubricant oil, heat medium oil, etc.
Appearance Light gray, silver
Dimensions (W×D×H (mm)) 350×450×675 350×450×825 410×550×925 520×620×1015
Weight (kg) 60 75 95 135
* The operating current indicates the normal operating current, not the maximum operating current.
* The effective cooling capacity indicates the maximum values within the range of use when oil ISO VG2 or equivalent is used.
* Specifications are subject to change without notice for improvement.
Series CL specifications Gas bypass PID control method
Model
CL175 CL300 CL750 CL1100
Effective cooling capacity
(W)(50/60Hz)
580/650 1160/1390 2800/2900 4000/4500
Nominal chiller capacity (W) 130W 300W 750W 1100W
Refrigerant used R-134a R-407C
Amount of refrigerant filled (g) 280 420 560 700
Condenser Forced air-cooled type parallel flow type
Rated output of fan motor (W) 10 25 60 60/25
Cooler (evaporator) Plate-type heat exchanger
Heating exchange method Constant-flow forced circulation
Solution-sending pump type Trochoid gear pump
Rated output of motor (W) 200 400
Flow rate (L/M) (50/60Hz) 6.0/7.2 12/14.4 24/28.8
Total relief pressure (Mpa) 0.5
Size of connected pipes (IN×OUT) RC1/2×RC1/2 RC3/4×RC1/2
Power source AC200V 50/60Hz, AC220V 60Hz, 3-phase
Maximum operating current (A) 3 5 8 19
Normal operating current (A) ― ― ― ―
Temperature regulator Digital PID controller
Setting range
Constant type (5-45°C),
follow-up type (reference temperature: -9.9°C - +9.9°C)
Range of ambient temperature 5-45 (°C)
Range of liquid temperature 5-45 (°C)
Fluid to use Mineral operating oil, lubricant oil, heat medium oil, etc.
Appearance Light gray
Dimensions (W×D×H (mm)) 300×508×485 350×450×675 350×450×825 400×470×880
Weight (kg) 40 60 75 80
* The operating current indicates the normal operating current, not the maximum operating current.
* The effective cooling capacity indicates the maximum values within the range of use when oil ISO VG2 or equivalent is used.
* Specifications are subject to change without notice for improvement.
