Specifications

OIL MATIC series C, CL and ML
OIL MATIC models for cooling main spindle, operating oil and lubricant oil
C/CL/ML Series
Circulation (closed) type
A “standard” model
supporting high precision of
every machine tool
For temperature control of main spindle
cooling oil, operating oil and hollow ball
screws of machine tools, we have a lineup of
three control met
hods according to accuracy.
The series C and CL can control a wide
range of liquid temperature by adopting
Kanto Seiki’s unique technology called
“twin-pulse valve control” (patented) for
high-precision control of liquid temperature
even in the case of small heat generation
(low load), which makes them useful for
microfabrication and high-precision finishing.
C750 (without tank)
Cools
main
spindle
Cools
operating
oil
Cools
lubricant
oil
Cools
linear
motor
Cools ball
screws
Cools
machine
body
Product specifications
Product specifications

Cools main spindle of
machine tools, etc.
Cools hydraulic oil
 Cools lubricant oil, etc.
Condenser
Drier
Fan motor
(M21)
Receiver tank
Sensor
Pulse
expansion
valve
Cooler
Reservoir tank
Trochoid gear
pump motor
Service valve
Inverter
compressor
(M2)
Pulse
bypass valve
Sight
glass
OIL MATIC
Sensor
Condenser
Cooler
Sensor
Compressor
Trochoid gear
pump motor
Pressure switch (GPS)
