Take Apart Logic Board - 24
Note:
The NVRAM on the
logic board contains the
information used to set the
“customer mode”, and
carriage XY calibration.
Replacing the logic board or
mechanical assembly
requires re-calibration of
the printer.
See “Default Settings” and
“X-Y Calibration” in
Additional Procedures for
more information.
