Additional Procedures Interpreting the NVM (Non-Volatile Memory) Grid - 64
Using the NVM Hex Decoder Transparency
To interpret the NVRAM grid, follow these
instructions:
1 Print a transparency of the NVM hex decoder shown on
the next page.
2 Locate the “NVM:” heading on the bottom portion of
the Extended Diagnostic test page. There are 20
columns and 13 rows on the NVM grid that follow a
hexadecimal representation of the information held in
NVRAM.
3 Determine what information you want to extract from
the grid (reference the NVRAM data table at the end of
this section to give you an idea).
4 Place the decoder transparency on top of the NVM grid
located on the Extended Diagnostic test page.
