Additional Procedures X-Y Calibration - 51
7 Using the print-out, verify that the X and Y values were
properly written to printer memory. The X and Y values
are the third and fourth values in the fifth row of the
map printed at the bottom of the Extended Diagnostic Test
page.
Note: The values are hexadecimal numbers representing
8-bit signed numbers. “02” is 2, “01” is 1, “00” is
0, “ff” is -1, “fe” is -2, and so on.
