Take Apart Mechanical Assembly - 60
Important: Never adjust any screws on the mechanical
assembly. Doing so will require replacement of the
mechanical assembly.
Note: The NVRAM on the logic board contains the
information used to set the “customer mode” Default
Settings, and carriage XY calibration. Replacing the logic
board or mechanical assembly requires re-calibration of
the printer.
See “Default Settings” and “X-Y Calibration” in Additional
Procedures for procedures.
