12.
Adjust the car
d so its connector lines up with the
connector on the slot.
Don
’t press the connectors together yet.
13.
Insert the two pins on the dock bracket into the slot
and hole on the card bracket.
Hole
Pin
Slot
Pin
Align connectors
