Take Apart
Floppy
Drive -
26
4
Disconnect the floppy
drive cable.
Note:
You
can
easily
reach the floppy drive
cable connector when the
floppy drive is forward.
5
Slide out the floppy
drive.
Floppy
Drive
Cable
1
...
...
