Take Apart
Power
Supply -
6
3
Disconnect these power
supply cables
•
Main power cable
•
Hard drive power
cable
•
CD-ROM drive power
cable (if installed)
Main
Power Cable
CD-ROM Drive
Power Cable
Hard Drive
Power Cable
