Upgrades
Power Macintosh Upgrade
-
4
1
2
0
Re
place the power
supply.
2
1
Tighten the screw that
secures the power
supply to the chassis.
22
Push in the CD-ROM
drive until you hear it
click into place.
Power Supply
