Upgrades
Power Macintosh Upgrade
-
4
0
1
9
Reconnect these power
supply cables
•
Main power cable
•
Hard drive power
cable
•
CD-ROM drive power
cable (if installed)
Main Power
Cable
CD-ROM Drive
Power Cable
Hard Drive
Power Cable
