Upgrades
DOS Compatibility Upgrade
-
2
3
Note:
Make sure that the tab
on the side of the adapter
card slides into the slot on
the side of the bottom
housing.
Adapter Card Tab
Adapter Card
Connector
Bottom Case
Slot
Expansion Slot
