Appendix A – Specifications
System O.S. Embedded Linux 3.0
Multiplex Sixfold operation - simultaneous record, live,
playback, backup, control, & remote access
Certification FCC, CE, etc.
Video Format HD: HD-SDI, Analog: NTSC/EIA or PAL/CCIR
Input HD: 2/4-CH HD-SDI (SMPTE 292M), BNC, 0.8Vp-p
/75ohm, up to 1080p30, 720p60
Analog: 12/8/0-CH, BNC, 1Vp-p/75ohm
Main monitor HDMI, with resolution 1920x1080,
VGA D-SUB 15-pin, with resolution 1920x1080,
BNC x 1, 1Vp-p/75ohm
Call monitor BNC x 1, 1Vp-p/75ohm
Loss detection Yes
Motion detection Yes, with configurable detection area & sensitivity
Privacy mask Yes
Audio Input HD: 2/4-CH, BNC, same as Video Input
Analog: 16/10/4 RCA-jack connectors, line-in level
(100mV-2Vrms)
Output HDMI,
2 RCA-jack connectors, line-out level (up to 2Vrms)
Record Compression Video:
H.264
High Profile
,
Audio: ADPCM
Max frame rate
& resolution
HD: 1080p/720p (60/50)/(120/100),
Full-D1: (360/300)/(240/200)
Mode Manual/Schedule/Alarm/Motion/Panic
Pre-record time 0 – 10 seconds
Post-record time 0 - 60 minutes
Display Resolution HDMI/VGA – 1920x1080
NTSC – 720*480, PAL – 720*576
Split windows 1/4/8/12/16, 1/4/5/10 or 1/4
Frame rate Up to 30 (NTSC) / 25 (PAL) IPS per display window
Sequential switch User adjustable
Digital Zoom X2, X4
Playback Max frame rate
& resolution
HD: 720p (60/50)/(120/100), 1080p (60/50)/50/100,
Full-D1: (360/300)/(240/200)
Search
Smart search
, Date/time, Camera, Alarm, Motion,
Video Loss, & Panic
Operation Play, Fast Forward, Backward, Pause, Stop, etc.
Remote I.E. and HEM can also Print, Snapshot
Storage HDD Up to 5/2 sets of 3.5” SATA type HDDs,
> 3TB for each HDD,
Failure detection & privacy law supported
HDD Extension 1 eSATA connector for eSATA HDD
Partitions Configurable alarm partition size
Configurable auto-overwrite or not
